IB-DK2512-TB3 Wired Thunderbolt 3 Black
Model IB-DK2512-TB3Part no. 60722EAN 4250078170570
46 specifications
- ConnectivityWired
- Weight300 g
- ColourBlack
- Ethernet LANYes
- Power source typeAC
- Width83 mm
Overview
- Connectivity
- Wired
- Weight
- 300 g
- Colour
- Black
- Ethernet LAN
- Yes
- Power source type
- AC
- Width
- 83 mm
- Brand
- ICY BOX
- Category
- Laptop Docks & Port Replicators
- Model
- IB-DK2512-TB3
- Part number
- 60722
- EAN / UPC
- 4250078170570
- Also known as
- ICY BOX IB-DK2512-TB3 Wired Thunderbolt 3 Black
Specifications
46 specifications in 8 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| Host interface | Thunderbolt 3 |
| USB 2.0 ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| USB Power Delivery (USB PD) | Yes |
| USB Power Delivery up to | 60 W |
| HDMI ports quantity | 0 |
| DisplayPorts quantity | 2 |
| Microphone in | No |
| Combo headphone/mic port | Yes |
| Headphone outputs | 0 |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
Performance
| Specification | Value |
|---|---|
| Product colour | Black |
| Card reader integrated | No |
| Data transfer rate | 19 Gbit/s |
| HD type | 8K Ultra HD |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| On/off switch | Yes |
| Housing material | Acrylonitrile butadiene styrene (ABS) |
| LED indicators | Yes |
| Country of origin | China |
Power
| Specification | Value |
|---|---|
| Power source type | AC |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Input current | 2 A |
| Power supply | 130 W |
| Power cable length | 0.7 m |
Software
| Specification | Value |
|---|---|
| Windows operating systems supported | Yes |
| Mac operating systems supported | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 83 mm |
| Depth | 210 mm |
| Height | 30 mm |
| Weight | 300 g |
Packaging data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
| Package width | 137 mm |
| Package depth | 268 mm |
| Package height | 105 mm |
| Package weight | 1.4 kg |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Cables included | AC, Thunderbolt |
| Manual | Yes |
