IB-DK2254AC Wired USB 3.2 Gen 2 (3.1 Gen 2) Type-C Black
Model IB-DK2254ACPart no. 60802EAN 4250078171386
44 specifications
- ConnectivityWired
- Weight287 g
- ColourBlack
- Ethernet LANYes
- Power source typeAC
- Width230 mm
Overview
- Connectivity
- Wired
- Weight
- 287 g
- Colour
- Black
- Ethernet LAN
- Yes
- Power source type
- AC
- Width
- 230 mm
- Brand
- ICY BOX
- Category
- Laptop Docks & Port Replicators
- Model
- IB-DK2254AC
- Part number
- 60802
- EAN / UPC
- 4250078171386
- Also known as
- ICY BOX IB-DK2254AC Wired USB 3.2 Gen 2 (3.1 Gen 2) Type-C Black
Specifications
44 specifications in 9 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| Host interface | USB 3.2 Gen 2 (3.1 Gen 2) Type-C |
| USB 2.0 ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 6 |
| USB Power Delivery (USB PD) | Yes |
| HDMI ports quantity | 3 |
| DisplayPorts quantity | 3 |
| Microphone in | No |
| Combo headphone/mic port | Yes |
| Headphone outputs | 0 |
| DC-in jack | Yes |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
Performance
| Specification | Value |
|---|---|
| Product colour | Black |
| Card reader integrated | No |
| HD type | 4K Ultra HD |
| Maximum digital resolution | 3840 x 2160 pixels |
| Housing material | Plastic |
| LED indicators | Yes |
| UASP support | Yes |
| Country of origin | Thailand |
Power
| Specification | Value |
|---|---|
| Power source type | AC |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power supply | 135 W |
| Output current | 6.75 A |
| Output voltage | 20 V |
Software
| Specification | Value |
|---|---|
| Windows operating systems supported | Yes |
| Mac operating systems supported | Yes |
| Other operating systems supported | ChromeOS |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 230 mm |
| Depth | 150 mm |
| Height | 85 mm |
| Weight | 287 g |
Packaging data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
| Package width | 250 mm |
| Package depth | 360 mm |
| Package height | 185 mm |
| Package weight | 1.22 kg |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Cables included | AC, USB |
| Manual | Yes |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84733020 |
