Thunderbolt4 Triple Display Docking Station + Power Delivery
96W
Model TB4TRIPLEDOCKPDITEAN 8595611707452
37 specifications
- ConnectivityWired
- Weight460 g
- ColourBlack
- Ethernet LANYes
- Power source typeAC
- Width217 mm
Overview
- Connectivity
- Wired
- Weight
- 460 g
- Colour
- Black
- Ethernet LAN
- Yes
- Power source type
- AC
- Width
- 217 mm
- Brand
- i-tec
- Category
- Laptop Docks & Port Replicators
- Model
- TB4TRIPLEDOCKPDIT
- Part number
- TB4TRIPLEDOCKPDIT
- EAN / UPC
- 8595611707452
- Also known as
- i-tec Thunderbolt4 Triple Display Docking Station + Power Delivery 96W
Specifications
37 specifications in 7 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| Host interface | Thunderbolt 4 |
| USB 2.0 ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| USB Power Delivery (USB PD) | Yes |
| USB Power Delivery up to | 96 W |
| HDMI ports quantity | 2 |
| Combo headphone/mic port | Yes |
| Headphone connectivity | 3.5 mm |
| DC-in jack | Yes |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Ethernet LAN data rates | 10,100,1000,2500 Mbit/s |
Performance
| Specification | Value |
|---|---|
| Product colour | Black |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash), SD |
| Data transfer rate | 40 Gbit/s |
| Maximum refresh rate | 144 Hz |
| Number of displays supported | 3 |
Power
| Specification | Value |
|---|---|
| Power source type | AC |
| Power supply | 160 W |
| Output current | 8 A |
| Output voltage | 20 V |
| Thunderbolt 4 cable length | 1 m |
Software
| Specification | Value |
|---|---|
| Windows operating systems supported | Yes |
| Mac operating systems supported | Yes |
| Linux operating systems supported | Yes |
| Mobile operating systems supported | Android, iOS |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 217 mm |
| Depth | 81.3 mm |
| Height | 28.8 mm |
| Weight | 460 g |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Cables included | Thunderbolt |
| Manual | Yes |
