Thunderbolt 3 Travel Dock Dual 4K Display with Power Delivery
60W + Universal Charger 77 W
Model TB3TRAVELDPD60USEAN 8595611706189
41 specifications
- ConnectivityWired
- Weight210 g
- ColourBlack
- Ethernet LANYes
- Power source typeAC
- Operating temperature (T-T)0 - 40 °C
Overview
- Connectivity
- Wired
- Weight
- 210 g
- Colour
- Black
- Ethernet LAN
- Yes
- Power source type
- AC
- Operating temperature (T-T)
- 0 - 40 °C
- Brand
- i-tec
- Category
- Laptop Docks & Port Replicators
- Model
- TB3TRAVELDPD60US
- Part number
- TB3TRAVELDPD60US
- EAN / UPC
- 8595611706189
- Also known as
- i-tec Thunderbolt 3 Travel Dock Dual 4K Display with Power Delivery 60W + Universal Charger 77 W
Specifications
41 specifications in 9 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| Host interface | Thunderbolt 3 |
| USB 2.0 ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| USB Power Delivery (USB PD) | Yes |
| USB Power Delivery up to | 60 W |
| HDMI ports quantity | 1 |
| DisplayPorts quantity | 1 |
| Combo headphone/mic port | Yes |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
Performance
| Specification | Value |
|---|---|
| Product colour | Black |
| Card reader integrated | No |
| Data transfer rate | 10 Gbit/s |
| HD type | 8K Ultra HD |
Power
| Specification | Value |
|---|---|
| Power source type | AC |
| AC input voltage | 100-240 V |
| AC input frequency | 50-60 Hz |
| Input current | 3.25 A |
| Power supply | 77 W |
| Output current | 5 A |
| Output voltage | 5/9/12/19/20 V |
| Compatible power plug types | US |
| USB cable length | 0.18 m |
Software
| Specification | Value |
|---|---|
| Windows operating systems supported | Yes |
| Mac operating systems supported | Yes |
| Linux operating systems supported | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 100% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 100 mm |
| Depth | 100 mm |
| Height | 28 mm |
| Weight | 210 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 133 mm |
| Package depth | 165 mm |
| Package height | 38 mm |
| Package weight | 300 g |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Manual | Yes |
