USB-C HDMI DP Docking Station with Power Delivery
65W + Universal Charger 77 W
Model C31HDMIDPDOCKPD65EAN 8595611704772
49 specifications
- ConnectivityWired
- ColourBlack
- Ethernet LANYes
- Power source typeAC, USB
- Operating temperature (T-T)0 - 40 °C
- Width113 mm
Overview
- Connectivity
- Wired
- Colour
- Black
- Ethernet LAN
- Yes
- Power source type
- AC, USB
- Operating temperature (T-T)
- 0 - 40 °C
- Width
- 113 mm
- Brand
- i-tec
- Category
- Laptop Docks & Port Replicators
- Model
- C31HDMIDPDOCKPD65
- Part number
- C31HDMIDPDOCKPD65
- EAN / UPC
- 8595611704772
- Also known as
- i-tec USB-C HDMI DP Docking Station with Power Delivery 65W + Universal Charger 77 W
Specifications
49 specifications in 10 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| Host interface | USB 3.2 Gen 1 (3.1 Gen 1) Type-C |
| USB 2.0 ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 2 |
| USB Power Delivery (USB PD) | Yes |
| USB Power Delivery up to | 65 W |
| HDMI ports quantity | 1 |
| DisplayPorts quantity | 1 |
| Combo headphone/mic port | Yes |
| Headphone connectivity | 3.5 mm |
| DC-in jack | No |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
Performance
| Specification | Value |
|---|---|
| Product colour | Black |
| Card reader integrated | No |
| HD type | 4K Ultra HD |
| Maximum digital resolution | 3840 x 2160 pixels |
| Maximum refresh rate | 60 Hz |
| Number of displays supported | 2 |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| VESA mounting | Yes |
| On/off switch | Yes |
| LED indicators | Yes |
Power
| Specification | Value |
|---|---|
| Power source type | AC, USB |
| AC input voltage | 100-240 V |
| AC input frequency | 50-60 Hz |
| Power supply | 77 W |
| Output current | 3.25 A |
| Output voltage | 5, 9, 12, 15, 20 V |
| Compatible power plug types | EU |
| Wireless charging | No |
Software
| Specification | Value |
|---|---|
| Windows operating systems supported | Yes |
| Mac operating systems supported | Yes |
| Linux operating systems supported | Yes |
| Other operating systems supported | Android |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 113 mm |
| Depth | 113 mm |
| Height | 40 mm |
Packaging data
| Specification | Value |
|---|---|
| Package width | 338 mm |
| Package depth | 150 mm |
| Package height | 55 mm |
| Package weight | 828 g |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Quick start guide | Yes |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84733020 |
