GLB232004 laptop dock/port replicator Wired Black
Model GLB232004EAN 5704174863380
61 specifications
- ConnectivityWired
- Weight850 g
- ColourBlack
- Ethernet LANYes
- Power source typeAC
- Storage temperature (T-T)-10 - 55 °C
Overview
- Connectivity
- Wired
- Weight
- 850 g
- Colour
- Black
- Ethernet LAN
- Yes
- Power source type
- AC
- Storage temperature (T-T)
- -10 - 55 °C
- Brand
- eSTUFF
- Category
- Laptop Docks & Port Replicators
- Model
- GLB232004
- Part number
- GLB232004
- EAN / UPC
- 5704174863380
- Also known as
- eSTUFF GLB232004 laptop dock/port replicator Wired Black
Specifications
61 specifications in 11 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| USB 2.0 ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| USB Power Delivery (USB PD) | Yes |
| USB Power Delivery revision | 3.0 |
| USB Power Delivery up to | 100 W |
| HDMI ports quantity | 3 |
| HDMI version | 2.0 |
| DisplayPorts quantity | 2 |
| Microphone in | Yes |
| Headphone outputs | 1 |
| Headphone connectivity | 3.5 mm |
| DC-in jack | Yes |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Ethernet LAN data rates | 1000 Mbit/s |
| Wake-on-LAN ready | No |
Performance
| Specification | Value |
|---|---|
| Product colour | Black |
| Card reader integrated | No |
| Data transfer rate | 10 Gbit/s |
| Maximum refresh rate | 60 Hz |
| Number of displays supported | 3 |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| On/off switch | Yes |
| Charging function | Yes |
| Housing material | Metal |
| LED indicators | Power |
| Rubber feet | Yes |
| Brand compatibility | Universal |
Power
| Specification | Value |
|---|---|
| Power source type | AC |
| AC input voltage | 100 - 240 V |
| Power supply | 130 W |
| Output current | 5.41 A |
| Output voltage | 24 V |
Software
| Specification | Value |
|---|---|
| Windows operating systems supported | Yes |
| Mac operating systems supported | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Storage temperature (T-T) | -10 - 55 °C |
| Storage relative humidity (H-H) | 0 - 85% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 191 mm |
| Depth | 85 mm |
| Height | 31.8 mm |
| Weight | 850 g |
Packaging data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
| Package width | 280 mm |
| Package depth | 210 mm |
| Package height | 42 mm |
| Package weight | 1.1 kg |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Cables included | AC |
| Quick start guide | Yes |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
Other features
| Specification | Value |
|---|---|
| Cable length | 0.5 m |
| Chipset | Displaylink® DL-6950 |
| Microphone connectivity | 3.5 mm |
| USB data transfer rates | 10000 Mbit/s |
| USB ports quantity | 5 |
| I/O ports | 15 |
