TB16 Wired Thunderbolt 3 Black
Model TB16Part no. 452-BCOUEAN 5704174092193
33 specifications
- ConnectivityWired
- ColourBlack
- Ethernet LANYes
- Power source typeAC
- Width145 mm
Overview
- Connectivity
- Wired
- Colour
- Black
- Ethernet LAN
- Yes
- Power source type
- AC
- Width
- 145 mm
- Brand
- Dell
- Category
- Laptop Docks & Port Replicators
- Model
- TB16
- Part numbers
- 452-BCOU, 452-BCOV, 452-BCPB, 5K5RK, 452-BCNU, 452-BCNP +7 more
- EAN / UPC
- 5704174092193, 5704174092179, 8944467978149, 884116256809 +20 more
- Also known as
- DELL TB16 Wired Thunderbolt 3 Black
Specifications
33 specifications in 8 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| Host interface | Thunderbolt 3 |
| USB 2.0 ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| HDMI ports quantity | 1 |
| VGA (D-Sub) ports quantity | 1 |
| DisplayPorts quantity | 1 |
| Mini DisplayPorts quantity | 1 |
| Thunderbolt 3 ports quantity | 1 |
| Combo headphone/mic port | Yes |
| Headphone outputs | 1 |
| Headphone connectivity | 3.5 mm |
| Line-out | Yes |
| DC-in jack | Yes |
| USB connector type | USB Type-A |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
Performance
| Specification | Value |
|---|---|
| Product colour | Black |
| Card reader integrated | No |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| LED indicators | Yes |
| Brand compatibility | Dell |
Power
| Specification | Value |
|---|---|
| Power source type | AC |
| Output voltage | 19.5 V |
| Power consumption (max) | 240 W |
Software
| Specification | Value |
|---|---|
| Windows operating systems supported | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 145 mm |
| Depth | 145 mm |
| Height | 51 mm |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84733020 |
