Dataflex Viewlite link USB-C docking station EUR - option 802

Dataflex Viewlite link USB-C docking station EUR - option 802

Model 58.802EAN 805410588021

63 specifications
  • ConnectivityWired
  • ColourAluminium
  • Ethernet LANYes
  • Built-in speaker(s)No
  • Power source typeDC
  • Operating temperature (T-T)0 - 40 °C
See all specifications

Overview

Connectivity
Wired
Colour
Aluminium
Ethernet LAN
Yes
Built-in speaker(s)
No
Power source type
DC
Operating temperature (T-T)
0 - 40 °C
Brand
Dataflex
Model
58.802
Part number
58.802
EAN / UPC
805410588021
Also known as
Dataflex Viewlite link USB-C docking station EUR - option 802

Specifications

63 specifications in 15 groups

Ports & interfaces

Connectivity technologyWired
Host interfaceUSB 3.2 Gen 1 (3.1 Gen 1) Type-C
USB 2.0 ports quantity2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity0
HDMI ports quantity2
HDMI version1.4
Microphone inNo
Headphone outputs0

Network

Ethernet LANYes
Ethernet LAN (RJ-45) ports1

Performance

Product colourAluminium
Card reader integratedNo
Optical drive includedNo
Data transfer rate5 Gbit/s
Maximum digital resolution4096 x 2160 pixels
Maximum analog resolution4096 x 2160 pixels
Number of displays supported2
Cable lock slotYes
Cable lock slot typeKensington
On/off switchNo
Charging functionYes
Plug and PlayYes
Reset buttonNo
Rubber feetYes
Country of originNetherlands

Audio

Built-in speaker(s)No

Cooling

Built-in fanNo

Storage

Built-in HDDNo

Power

Power source typeDC
AC input voltage100 - 240 V
Power supply typeExternal
Output current3.75 A
Output voltage24 V
Power consumption (typical)90 W
Power consumption (standby)2 W
Built-in batteryNo

Software

Windows operating systems supportedWindows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64
Mac compatibilityYes
Mac operating systems supportedMac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra

Control unit

Remote control includedNo

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-15 - 50 °C
Operating relative humidity (H-H)20 - 80%
Storage relative humidity (H-H)10 - 90%
Operating altitude0 - 2000 m
Non-operating altitude0 - 12000 m

Weight & dimensions

Width315 mm
Depth110 mm
Height32 mm

Packaging data

Quantity per pack1 pc(s)
Package width388 mm
Package depth165 mm
Package height120 mm
Package weight1.38 kg

Packaging content

AC adapter includedYes
Cables includedUSB Type-C
Quick start guideYes

Logistics data

Harmonized System (HS) code84733020

Other features

Light effectsNo
USB data transfer rates480,5000 Mbit/s
