Conceptronic DONN34G 10-in-1 USB 3.2 Gen 2 MST Docking Station, 4K60Hz HDMI, 8K30Hz DisplayPort, GbE, USB-C 10Gbps x 3, USB-A 480Mbps x 2, Audio
Conceptronic

DONN34G 10-in-1 USB 3.2 Gen 2 MST Docking Station, 4K60Hz HDMI, 8K30Hz DisplayPort, GbE, USB-C 10Gbps x 3, USB-A 480Mbps x 2, Audio

100W USB PD

Model DONN34GEAN 4015867243992

53 specifications
  • ConnectivityWired
  • Weight157 g
  • ColourGrey
  • Ethernet LANYes
  • USB cable length0.2 m
  • Operating temperature (T-T)0 - 45 °C
See all specifications

Overview

Connectivity
Wired
Weight
157 g
Colour
Grey
Ethernet LAN
Yes
USB cable length
0.2 m
Operating temperature (T-T)
0 - 45 °C
Brand
Conceptronic
Model
DONN34G
Part number
DONN34G
EAN / UPC
4015867243992
Also known as
Conceptronic DONN34G 10-in-1 USB 3.2 Gen 2 MST Docking Station, 4K60Hz HDMI, 8K30Hz DisplayPort, GbE, USB-C 10Gbps x 3, USB-A 480Mbps x 2, Audio, 100W USB PD

Specifications

53 specifications in 12 groups

Ports & interfaces

Connectivity technologyWired
Host interfaceUSB 3.2 Gen 2 (3.1 Gen 2) Type-C
USB 2.0 ports quantity2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity0
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity4
USB Power Delivery (USB PD)Yes
USB Power Delivery revision3.0
USB Power Delivery up to100 W
HDMI ports quantity1
HDMI version2.0
DisplayPorts quantity1
DisplayPort version1.4
Combo headphone/mic portYes
Headphone outputs1
Headphone connectivity3.5 mm

Network

Ethernet LANYes
Ethernet LAN (RJ-45) ports1
Ethernet LAN data rates10,100,1000 Mbit/s
Wake-on-LAN readyYes
Networking standardsIEEE 802.3ab

Performance

Product colourGrey
Card reader integratedNo
Data transfer rate10 Gbit/s
HD type8K Ultra HD
Maximum digital resolution7680 x 4320 pixels
Housing materialAluminium
Plug and PlayYes
Country of originChina

Power

USB cable length0.2 m

Software

Windows operating systems supportedYes
Mac operating systems supportedYes
Other operating systems supportedChromeOS

Operational conditions

Operating temperature (T-T)0 - 45 °C

Weight & dimensions

Width64.6 mm
Depth120 mm
Height17 mm
Weight157 g

Packaging data

Package width95 mm
Package depth200 mm
Package height20 mm
Package weight200 g

Packaging content

Quick start guideYes

Technical details

Compliance certificatesCE, RoHS

Logistics data

Customs product code (TARIC)8471800000
Master (outer) case gross weight8.9 kg
Master (outer) case height255 mm
Master (outer) case length400 mm
Master (outer) case width220 mm
Products per master (outer) case40 pc(s)
Pallet gross width120 cm
Pallet gross length80 cm
Pallet gross height168.2 cm

Other features

Master (outer) cases per pallet60 pc(s)
