ABBY25G USB-C to Gigabit Network Adapter with 3-Port USB Hub
Model ABBY25GEAN 4015867243695
45 specifications
- ConnectivityWired
- Weight42 g
- ColourGrey
- Ethernet LANYes
- USB cable length0.18 m
- Operating temperature (T-T)0 - 40 °C
Overview
- Connectivity
- Wired
- Weight
- 42 g
- Colour
- Grey
- Ethernet LAN
- Yes
- USB cable length
- 0.18 m
- Operating temperature (T-T)
- 0 - 40 °C
- Brand
- Conceptronic
- Category
- Laptop Docks & Port Replicators
- Model
- ABBY25G
- Part number
- ABBY25G
- EAN / UPC
- 4015867243695
- Also known as
- Conceptronic ABBY25G USB-C to Gigabit Network Adapter with 3-Port USB Hub
Specifications
45 specifications in 12 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| Host interface | USB 3.2 Gen 1 (3.1 Gen 1) Type-A + Type-C |
| USB 2.0 ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| HDMI ports quantity | 0 |
| Microphone in | No |
| Headphone outputs | 0 |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Wake-on-LAN ready | Yes |
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3az |
Performance
| Specification | Value |
|---|---|
| Product colour | Grey |
| Card reader integrated | No |
| Data transfer rate | 5 Gbit/s |
| Housing material | Aluminium |
| Plug and Play | Yes |
| Country of origin | China |
Power
| Specification | Value |
|---|---|
| USB cable length | 0.18 m |
Software
| Specification | Value |
|---|---|
| Windows operating systems supported | Yes |
| Mac operating systems supported | Yes |
| Linux operating systems supported | Yes |
| Mobile operating systems supported | Android |
| Other operating systems supported | ChromeOS |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 24 mm |
| Depth | 16.5 mm |
| Height | 89.6 mm |
| Weight | 42 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 85 mm |
| Package depth | 22 mm |
| Package height | 158 mm |
| Package weight | 75 g |
Packaging content
| Specification | Value |
|---|---|
| Quick start guide | Yes |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | CE, RoHS |
Logistics data
| Specification | Value |
|---|---|
| Customs product code (TARIC) | 8471800000 |
| Master (outer) case gross weight | 8.1 kg |
| Master (outer) case height | 250 mm |
| Master (outer) case length | 290 mm |
| Master (outer) case width | 440 mm |
| Products per master (outer) case | 100 pc(s) |
| Pallet gross width | 120 cm |
| Pallet gross length | 80 cm |
| Pallet gross height | 165.2 cm |
Other features
| Specification | Value |
|---|---|
| Master (outer) cases per pallet | 30 pc(s) |
