CLUB3D SenseVision USB3.0 Y-Cabled Docking Station

CLUB3D SenseVision USB3.0 Y-Cabled Docking Station

Model SenseVision USB3.0 Y-Cabled Docking StationPart no. CSV-3203EAN 854365005855

42 specifications
  • ConnectivityWired
  • Weight300 g
  • ColourBlack, Grey
  • Ethernet LANYes
  • Power source typeAC
  • Mac compatibilityNo
See all specifications

Overview

Connectivity
Wired
Weight
300 g
Colour
Black, Grey
Ethernet LAN
Yes
Power source type
AC
Mac compatibility
No
Brand
CLUB3D
Model
SenseVision USB3.0 Y-Cabled Docking Station
Part number
CSV-3203
EAN / UPC
854365005855, 8717249401025
Also known as
CLUB3D SenseVision USB 3.0 + Dual Mini DisplayPort MST Docking Station

Specifications

42 specifications in 9 groups

Ports & interfaces

Connectivity technologyWired
Host interfaceUSB 3.2 Gen 1 (3.1 Gen 1) Type-A + Mini DisplayPort 1.2
USB 2.0 ports quantity0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity3
HDMI ports quantity0
Mini DisplayPorts quantity2
Microphone inNo
Headphone outputs1
Headphone connectivityUSB
Line-outYes
DC-in jackYes
USB connector typeUSB Type-A

Network

Ethernet LANYes
Ethernet LAN (RJ-45) ports1
Ethernet LAN data rates10,100,1000 Mbit/s
Full duplexYes

Performance

Product colourBlack, Grey
Card reader integratedNo
Maximum digital resolution3840 x 21060 pixels
Number of displays supported2
Charging functionYes
LED indicatorsOperation
Plug and PlayYes
Reset buttonYes
Country of originChina
CompatibilityGreat for Microsoft Surface Products. Fully featured MultiStreamTransport (MST) Functionality for the 2 Mini DP Outputs.
CertificationCE, RoHS, FCC, Microsoft Surface Certified

Power

Power source typeAC
Output current1.3 A
Output voltage15 V

Software

Windows operating systems supportedWindows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x6
Mac compatibilityNo

Weight & dimensions

Width155 mm
Depth98 mm
Height (front)1.95 cm
Weight300 g

Packaging content

AC adapter includedYes
Cables includedDisplayPort, USB
Quick start guideYes
User guideYes

Technical details

Compliance certificatesRoHS

Other features

USB data transfer rates5000 Mbit/s
