CLUB3D Docking station(Metal casing)1x USB Gen2 Type-C Female (data) 2x USB Gen2 Type-A Female 1x USB Gen1 Type-A Female 1x USB Type-A (RED) Smart Charging port
CLUB3D

Docking station(Metal casing)1x USB Gen2 Type-C Female (data) 2x USB Gen2 Type-A Female 1x USB Gen1 Type-A Female 1x USB Type-A (RED) Smart Charging port

Model CSV-1568EAN 841615102334

60 specifications
  • ConnectivityDocking
  • Weight563 g
  • ColourMetallic
  • Ethernet LANYes
  • Power source typeDC
  • Width139 mm
See all specifications

Overview

Connectivity
Docking
Weight
563 g
Colour
Metallic
Ethernet LAN
Yes
Power source type
DC
Width
139 mm
Brand
CLUB3D
Model
CSV-1568
Part number
CSV-1568
EAN / UPC
841615102334, 8719214472115
Also known as
CLUB3D Docking station(Metal casing)1x USB Gen2 Type-C Female (data) 2x USB Gen2 Type-A Female 1x USB Gen1 Type-A Female 1x USB Type-A (RED) Smart Charging port

Specifications

60 specifications in 11 groups

Ports & interfaces

Connectivity technologyDocking
Host interfaceUSB 3.2 Gen 2 (3.1 Gen 2) Type-C
USB 2.0 ports quantity0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity1
USB Power Delivery (USB PD)Yes
USB Power Delivery revision3.0
USB Power Delivery up to100 W
HDMI ports quantity2
VGA (D-Sub) ports quantity1
DisplayPorts quantity1
DisplayPort version1.4
Thunderbolt 3 Power DeliveryYes
Combo headphone/mic portYes
Headphone connectivity3.5 mm
DC-in jackYes
HDCPYes
HDCP version1.4/2.2
USB Type-C DisplayPort Alternate ModeYes

Network

Ethernet LANYes
Ethernet LAN (RJ-45) ports1

Performance

Product colourMetallic
Card reader integratedYes
Data transfer rate16.2 Gbit/s
Maximum refresh rate60 Hz
High Dynamic Range (HDR) supportedYes
Key lockYes
Plug and PlayYes
Country of originChina
Brand compatibilityApple
CompatibilityLenovo Dell Acer Asus MSI Toshiba Apple HP Razer
CertificationMeets ROHS, FCC, and CE EMI requirements

Power

Power source typeDC
Power connectorUSB Type-C
AC input voltage100 - 240 V
Power supply120 W
Power consumption (max)120 W
Power cable length1 m

Software

Windows operating systems supportedYes
Mac operating systems supportedYes

Weight & dimensions

Width139 mm
Depth90 mm
Height44 mm
Weight563 g

Packaging data

Quantity per pack1 pc(s)
Package width225 mm
Package depth155 mm
Package height97 mm
Package weight1.36 kg

Packaging content

AC adapter includedYes
Quick start guideYes
Stand includedYes

Packaging composition

Paper/cardboard packaging weight168 g
Plastic packaging weight5 g
Total paper/cardboard packaging weight0 g
Total plastic packaging weight0 g

Logistics data

Harmonized System (HS) code8473 3020

Other features

Special featuresIn the box: CSV-1568 Docking Station PowerSupply Input:100-110/240VAC, Output: up to 120W USB Gen2 Type-C cable 10G, 20V5A M/M, 1 m / 3.28 ft Detachable stand Quick Install Guide
Voltage20.5 V
