Triple Display USB-C Dock Duo DC301
Model Triple Display USB-C Dock Duo DC301Part no. 90XB0A5N-BDS010EAN 197105832244
42 specifications
- ConnectivityWired
- Weight514 g
- ColourBlack
- Ethernet LANYes
- Power source typeDC
- Width160 mm
Overview
- Connectivity
- Wired
- Weight
- 514 g
- Colour
- Black
- Ethernet LAN
- Yes
- Power source type
- DC
- Width
- 160 mm
- Brand
- ASUS
- Category
- Laptop Docks & Port Replicators
- Model
- Triple Display USB-C Dock Duo DC301
- Part numbers
- 90XB0A5N-BDS010, 90XB0A5N-BDS030
- EAN / UPC
- 197105832244, 4711387832240, 4711387832264
- Also known as
- ASUS Triple Display USB-C Dock Duo DC301 Wired Black
Specifications
42 specifications in 7 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| USB 2.0 ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 2 |
| USB Power Delivery (USB PD) | Yes |
| USB Power Delivery up to | 90 W |
| HDMI ports quantity | 1 |
| HDMI version | 2.0 |
| DisplayPorts quantity | 2 |
| DisplayPort version | 1.4 |
| Microphone in | No |
| Combo headphone/mic port | Yes |
| Headphone outputs | 0 |
| DC-in jack | Yes |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Ethernet LAN data rates | 1000 Mbit/s |
Performance
| Specification | Value |
|---|---|
| Product colour | Black |
| Card reader integrated | Yes |
| Compatible memory cards | SD |
| Data transfer rate | 10 Gbit/s |
| Maximum digital resolution | 3840 x 2160 pixels |
| Maximum refresh rate | 60 Hz |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| On/off switch | Yes |
Power
| Specification | Value |
|---|---|
| Power source type | DC |
| Input current | 7.5 A |
| Power supply | 150 W |
| Power cable length | 1 m |
| USB cable length | 1 m |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 160 mm |
| Depth | 80 mm |
| Height | 32 mm |
| Weight | 514 g |
Packaging data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
Packaging content
| Specification | Value |
|---|---|
| Warranty card | Yes |
| AC adapter included | Yes |
| Cables included | AC, USB Type-C |
| Manual | Yes |
| Stand included | Yes |
