MSI RADEON RX 6800 16G

RADEON RX 6800 16G

Model RADEON RX 6800 16GEAN 4719072957841

40 specifications Checked today

Weight1.4 kg
ColourBlack, Grey
Graphics processor familyAMD
Discrete graphics card memory16 GB
Interface typePCI Express x16 4.0
PhysXNo

See all specifications

Overview

Weight: 1.4 kg
Colour: Black, Grey
Graphics processor family: AMD
Discrete graphics card memory: 16 GB
Interface type: PCI Express x16 4.0
PhysX: No

Brand: MSI
Category: GPU
Model: RADEON RX 6800 16G
Part number: RADEON RX 6800 16G
EAN / UPC: 4719072957841
Also known as: MSI RADEON RX 6800 16G graphics card AMD 16 GB GDDR6

Specifications

40 specifications in 8 groups

Processor

Specification	Value
Graphics processor family	AMD
Graphics processor	Radeon RX 6800
Maximum resolution	7680 x 4320 pixels
CUDA	No
Processor frequency	1815 MHz
Processor boost clock speed	2105 MHz
Maximum displays per videocard	4

Memory

Specification	Value
Discrete graphics card memory	16 GB
Graphics card memory type	GDDR6
Memory bus	256 bit
Memory clock speed	16000 MHz

Ports & interfaces

Specification	Value
Interface type	PCI Express x16 4.0
HDMI ports quantity	1
DVI-D ports quantity	0
DVI-I ports quantity	0
DisplayPorts quantity	2
HDMI version	2.1
DisplayPort version	1.4
USB Type-C ports quantity	1
VGA (D-Sub) ports quantity	0

Performance

Specification	Value
PhysX	No
TV tuner integrated	No
DirectX version	12.0
OpenGL version	4.6
Virtual Reality (VR) ready	Yes
Dual Link DVI	No
AMD FreeSync	Yes

Design

Specification	Value
Cooling type	Active
Number of fans	3 fan(s)
Number of slots	2
Product colour	Black, Grey

Power

Specification	Value
Minimum system power supply	650 W
Power consumption (typical)	250 W
Supplementary power connectors	2x 8-pin

Weight & dimensions

Specification	Value
Weight	1.4 kg
Length	267 mm
Depth	40 mm
Height	120 mm

Packaging data

Specification	Value
Package weight	1.89 kg
Package type	Box
