MSI GeForce RTX 5070 Ti 16G VANGUARD SOC

GeForce RTX 5070 Ti 16G VANGUARD SOC

Model GeForce RTX 5070 Ti 16G VANGUARD SOCPart no. GEFORCE RTX 5070 TI 16G VANGUARD SOCEAN 824142402030

38 specifications Checked today

TypeFull-Height/Full-Length (FH/FL)
ColourBlack
Graphics processor familyNVIDIA
Discrete graphics card memory16 GB
Interface typePCI Express 5.0
TV tuner integratedNo

See all specifications

Overview

Type: Full-Height/Full-Length (FH/FL)
Colour: Black
Graphics processor family: NVIDIA
Discrete graphics card memory: 16 GB
Interface type: PCI Express 5.0
TV tuner integrated: No

Brand: MSI
Category: GPU
Model: GeForce RTX 5070 Ti 16G VANGUARD SOC
Part number: GEFORCE RTX 5070 TI 16G VANGUARD SOC
EAN / UPC: 824142402030, 4711377298377
Also known as: MSI GeForce RTX 5070 Ti 16G VANGUARD SOC NVIDIA 16 GB GDDR7

Specifications

38 specifications in 8 groups

Processor

Specification	Value
Graphics processor family	NVIDIA
Graphics processor	GeForce RTX 5070 Ti
Maximum resolution	7680 x 4320 pixels
CUDA	Yes
CUDA cores	8960
Maximum displays per videocard	4

Memory

Specification	Value
Discrete graphics card memory	16 GB
Graphics card memory type	GDDR7
Memory bus	256 bit
Data transfer rate	28 Gbit/s

Ports & interfaces

Specification	Value
Interface type	PCI Express 5.0
HDMI ports quantity	1
DVI-D ports quantity	0
DVI-I ports quantity	0
DisplayPorts quantity	3
Thunderbolt 3 ports quantity	0
Mini HDMI ports quantity	0
HDMI version	2.1b
DisplayPort version	2.1b
Mini DisplayPorts quantity	0

Performance

Specification	Value
TV tuner integrated	No
DirectX version	12 Ultimate
OpenGL version	4.6
HDCP	Yes
Dual Link DVI	No
NVIDIA G-SYNC	Yes
Overclocked (OC) edition	Yes

Design

Specification	Value
Cooling type	Active
Number of fans	3 fan(s)
Form factor	Full-Height/Full-Length (FH/FL)
Illumination	Yes
Illumination colour	Multi
Product colour	Black

Power

Specification	Value
Supplementary power connectors	1x 16-pin

Weight & dimensions

Specification	Value
Length	357 mm
Depth	151 mm
Height	66 mm

Packaging data

Specification	Value
Package type	Box
