4070 VENTUS 2X E1 12G OC
Model 4070 VENTUS 2X E1 12G OCPart no. GEFORCE RTX 4070 VENTUS 2X E1 12G OCEAN 4711377262019
44 specifications Checked today
- TypeFull-Height/Half-Length (FH/HL)
- Weight663 g
- ColourBlack, Silver
- Graphics processor familyNVIDIA
- Discrete graphics card memory12 GB
- Interface typePCI Express 4.0
Overview
- Type
- Full-Height/Half-Length (FH/HL)
- Weight
- 663 g
- Colour
- Black, Silver
- Graphics processor family
- NVIDIA
- Discrete graphics card memory
- 12 GB
- Interface type
- PCI Express 4.0
- Brand
- MSI
- Category
- GPU
- Model
- 4070 VENTUS 2X E1 12G OC
- Part number
- GEFORCE RTX 4070 VENTUS 2X E1 12G OC
- EAN / UPC
- 4711377262019
- Also known as
- MSI VENTUS 4070 2X E1 12G OC NVIDIA GeForce RTX 4070 12 GB GDDR6X
Specifications
44 specifications in 8 groups
Processor
| Specification | Value |
|---|---|
| Graphics processor family | NVIDIA |
| Graphics processor | GeForce RTX 4070 |
| Maximum resolution | 7680 x 4320 pixels |
| CUDA | Yes |
| CUDA cores | 5888 |
| Processor frequency | 2520 MHz |
| Processor boost clock speed | 2505 MHz |
| Maximum displays per videocard | 4 |
Memory
| Specification | Value |
|---|---|
| Discrete graphics card memory | 12 GB |
| Graphics card memory type | GDDR6X |
| Memory bus | 192 bit |
| Data transfer rate | 20 Gbit/s |
Ports & interfaces
| Specification | Value |
|---|---|
| Interface type | PCI Express 4.0 |
| HDMI ports quantity | 1 |
| DVI-D ports quantity | 0 |
| DVI-I ports quantity | 0 |
| DisplayPorts quantity | 3 |
| Thunderbolt 3 ports quantity | 0 |
| Mini HDMI ports quantity | 0 |
| HDMI version | 2.1a |
| DisplayPort version | 1.4a |
| Mini DisplayPorts quantity | 0 |
Performance
| Specification | Value |
|---|---|
| TV tuner integrated | No |
| DirectX version | 12 Ultimate |
| OpenGL version | 4.6 |
| HDCP | Yes |
| Dual Link DVI | No |
| NVIDIA G-SYNC | Yes |
| Overclocked (OC) edition | Yes |
Design
| Specification | Value |
|---|---|
| Cooling type | Active |
| Number of fans | 2 fan(s) |
| Form factor | Full-Height/Half-Length (FH/HL) |
| Number of slots | 2 |
| Illumination | No |
| SFF ready | No |
| Product colour | Black, Silver |
Power
| Specification | Value |
|---|---|
| Minimum system power supply | 650 W |
| Power consumption (typical) | 200 W |
| Supplementary power connectors | 1x 8-pin |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 663 g |
| Length | 241.3 mm |
| Depth | 43 mm |
| Height | 124.4 mm |
Packaging data
| Specification | Value |
|---|---|
| Package type | Box |
