NVIDIA RTX A4500
Model NVIDIA RTX A4500Part no. 4X61J77360EAN 195892059783
40 specifications Checked today
- Weight1.05 kg
- ColourBlack
- Graphics processor familyNVIDIA
- Discrete graphics card memory20 GB
- Interface typePCI Express x16 4.0
- TV tuner integratedNo
Overview
- Weight
- 1.05 kg
- Colour
- Black
- Graphics processor family
- NVIDIA
- Discrete graphics card memory
- 20 GB
- Interface type
- PCI Express x16 4.0
- TV tuner integrated
- No
- Brand
- Lenovo
- Category
- GPU
- Model
- NVIDIA RTX A4500
- Part number
- 4X61J77360
- EAN / UPC
- 195892059783, 4571591920627, 5054444533926
- Also known as
- Lenovo NVIDIA RTX A4500 20 GB GDDR6
Specifications
40 specifications in 11 groups
Processor
| Specification | Value |
|---|---|
| Graphics processor family | NVIDIA |
| Graphics processor | RTX A4500 |
| Maximum resolution | 7680 x 4320 pixels |
| CUDA | Yes |
| CUDA cores | 7168 |
| Maximum displays per videocard | 4 |
Memory
| Specification | Value |
|---|---|
| Discrete graphics card memory | 20 GB |
| Graphics card memory type | GDDR6 |
| Memory bus | 320 bit |
| Data transfer rate | 640 Gbit/s |
Ports & interfaces
| Specification | Value |
|---|---|
| Interface type | PCI Express x16 4.0 |
| HDMI ports quantity | 0 |
| DVI-D ports quantity | 0 |
| DVI-I ports quantity | 0 |
| DisplayPorts quantity | 4 |
| DisplayPort version | 1.4a |
Performance
| Specification | Value |
|---|---|
| TV tuner integrated | No |
| DirectX version | 12 Ultimate |
| Shader model version | 6.6 |
| OpenGL version | 4.6 |
| Virtual Reality (VR) ready | Yes |
Design
| Specification | Value |
|---|---|
| Cooling type | Active |
| Bracket height | Full-Height (FH) |
| Number of slots | 2 |
| Product colour | Black |
| Certification | BSMI, FCC, ICES, CE, VCCI, KCC, RCM, CB, Morocco |
Power
| Specification | Value |
|---|---|
| Minimum system power supply | 200 W |
| Supplementary power connectors | 1x 8-pin |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 45 °C |
| Operating relative humidity (H-H) | 5 - 95% |
System requirements
| Specification | Value |
|---|---|
| Windows operating systems supported | Windows 10, Windows 11 |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 1.05 kg |
| Length | 268.6 mm |
| Height | 111.2 mm |
Packaging data
| Specification | Value |
|---|---|
| Package width | 490 mm |
| Package depth | 220 mm |
| Package height | 92 mm |
| Package weight | 1.2 kg |
| Package type | Box |
Other features
| Specification | Value |
|---|---|
| Chipset | GA102-825 |
