Lenovo 00YL372 graphics card NVIDIA Quadro K2200 GDDR5
Model 00YL372EAN 889488106653
41 specifications Checked 2 days ago
- Weight240 g
- ColourBlack
- Graphics processor familyNVIDIA
- Graphics card memory typeGDDR5
- Interface typePCI Express 2.0
- PhysXNo
Overview
- Weight
- 240 g
- Colour
- Black
- Graphics processor family
- NVIDIA
- Graphics card memory type
- GDDR5
- Interface type
- PCI Express 2.0
- PhysX
- No
- Brand
- Lenovo
- Category
- GPU
- Model
- 00YL372
- Part number
- 00YL372
- EAN / UPC
- 889488106653
- Also known as
- Lenovo 00YL372 graphics card NVIDIA Quadro K2200 GDDR5
Specifications
41 specifications in 9 groups
Processor
| Specification | Value |
|---|---|
| Graphics processor family | NVIDIA |
| Graphics processor | Quadro K2200 |
| Maximum resolution | 4096 x 2160 pixels |
| CUDA | Yes |
| CUDA cores | 640 |
| Processor frequency | 1045 MHz |
| Maximum analog resolution | 2048 x 1536 pixels |
| Maximum digital resolution | 4096 x 2160 pixels |
Memory
| Specification | Value |
|---|---|
| Graphics card memory type | GDDR5 |
| Memory bus | 128 bit |
| Memory clock speed | 2500 MHz |
| Memory bandwidth (max) | 80 GB/s |
Ports & interfaces
| Specification | Value |
|---|---|
| Interface type | PCI Express 2.0 |
| HDMI ports quantity | 0 |
| DVI-D ports quantity | 0 |
| DVI-I ports quantity | 1 |
| DisplayPorts quantity | 2 |
| DisplayPort version | 1.2 |
| VGA (D-Sub) ports quantity | 0 |
Performance
| Specification | Value |
|---|---|
| PhysX | No |
| TV tuner integrated | No |
| DirectX version | 11.1 |
| Shader model version | 5.0 |
| OpenGL version | 4.4 |
| HDCP | Yes |
| Dual Link DVI | Yes |
| NVIDIA GameWorks VR | No |
| NVIDIA G-SYNC | No |
Design
| Specification | Value |
|---|---|
| Cooling type | Active |
| Product colour | Black |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 67.7 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 55 °C |
| Operating relative humidity (H-H) | 5 - 90% |
| Storage temperature (T-T) | -40 - 75 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 240 g |
| Length | 202.9 mm |
| Height | 111.5 mm |
Packaging data
| Specification | Value |
|---|---|
| Package width | 238 mm |
| Package depth | 144 mm |
| Package height | 54 mm |
| Package weight | 300 g |
