GIGABYTE Radeon RX 580 D5

Radeon RX 580 D5

8G

Model GV-RX580D5-8GDEAN 889523013373

40 specifications Checked today

TypeFull-Height/Full-Length (FH/FL)
ColourBlack, Orange
Graphics processor familyAMD
Discrete graphics card memory8 GB
Interface typePCI Express x16 3.0
PhysXNo

See all specifications

Overview

Type: Full-Height/Full-Length (FH/FL)
Colour: Black, Orange
Graphics processor family: AMD
Discrete graphics card memory: 8 GB
Interface type: PCI Express x16 3.0
PhysX: No

Brand: GIGABYTE
Category: GPU
Model: GV-RX580D5-8GD
Part number: GV-RX580D5-8GD
EAN / UPC: 889523013373
Also known as: GIGABYTE Radeon RX 580 D5 8G

Specifications

40 specifications in 9 groups

Processor

Specification	Value
Graphics processor family	AMD
Graphics processor	Radeon RX 580
Maximum resolution	7680 x 4320 pixels
CUDA	No
Processor frequency	1340 MHz
Processor frequency (OC mode)	1355 MHz
FireStream	Yes
Maximum displays per videocard	4
Stream processors	2304

Memory

Specification	Value
Discrete graphics card memory	8 GB
Graphics card memory type	GDDR5
Memory bus	256 bit
Memory clock speed	8000 MHz

Ports & interfaces

Specification	Value
Interface type	PCI Express x16 3.0
HDMI ports quantity	1
DVI-D ports quantity	0
DVI-I ports quantity	0
DisplayPorts quantity	3
HDMI version	2.0
DisplayPort version	1.4
VGA (D-Sub) ports quantity	0

Performance

Specification	Value
PhysX	No
TV tuner integrated	No
DirectX version	12.0
OpenGL version	4.5
HDCP	Yes
Dual Link DVI	No

Design

Specification	Value
Cooling type	Active
Number of fans	2 fan(s)
Bracket height	Full-Height (FH)
Form factor	Full-Height/Full-Length (FH/FL)
Number of slots	2
Product colour	Black, Orange

Power

Specification	Value
Minimum system power supply	500 W
Supplementary power connectors	1x 8-pin

System requirements

Specification	Value
Windows operating systems supported	Windows 10

Weight & dimensions

Specification	Value
Length	272 mm
Depth	39 mm
Height	131 mm

Packaging data

Specification	Value
Package type	Box
