GV-RX550D5-2GD REV2.0
Model GV-RX550D5-2GD REV2.0EAN 889523013014
37 specifications Checked today
- TypeHalf-Height/Half-Length (HH/HL)
- ColourBlack
- Graphics processor familyAMD
- Discrete graphics card memory2 GB
- Interface typePCI Express x8 3.0
- PhysXNo
Overview
- Type
- Half-Height/Half-Length (HH/HL)
- Colour
- Black
- Graphics processor family
- AMD
- Discrete graphics card memory
- 2 GB
- Interface type
- PCI Express x8 3.0
- PhysX
- No
- Brand
- GIGABYTE
- Category
- GPU
- Model
- GV-RX550D5-2GD REV2.0
- Part number
- GV-RX550D5-2GD REV2.0
- EAN / UPC
- 889523013014
- Also known as
- GIGABYTE GV-RX550D5-2GD REV2.0 graphics card AMD Radeon RX 550 2 GB GDDR5
Specifications
37 specifications in 7 groups
Processor
| Specification | Value |
|---|---|
| Graphics processor family | AMD |
| Graphics processor | Radeon RX 550 |
| Maximum resolution | 7860 x 4320 pixels |
| CUDA | No |
| Processor frequency (OC mode) | 1082 MHz |
| FireStream | No |
| Parallel processing technology support | Not supported |
Memory
| Specification | Value |
|---|---|
| Discrete graphics card memory | 2 GB |
| Graphics card memory type | GDDR5 |
| Memory bus | 128 bit |
| Memory clock speed | 6000 MHz |
Ports & interfaces
| Specification | Value |
|---|---|
| Interface type | PCI Express x8 3.0 |
| HDMI ports quantity | 1 |
| DVI-D ports quantity | 1 |
| DVI-I ports quantity | 0 |
| DisplayPorts quantity | 1 |
| HDMI version | 2.0b |
| DisplayPort version | 1.4 |
| VGA (D-Sub) ports quantity | 0 |
Performance
| Specification | Value |
|---|---|
| PhysX | No |
| TV tuner integrated | No |
| DirectX version | 12.0 |
| Shader model version | No |
| OpenGL version | 4.5 |
| HDCP | No |
| Dual Link DVI | Yes |
Design
| Specification | Value |
|---|---|
| Cooling type | Active |
| Number of fans | 1 fan(s) |
| Fan diameter | 9 cm |
| Bracket height | Low-Profile (LP) |
| Form factor | Half-Height/Half-Length (HH/HL) |
| Number of slots | 2 |
| Product colour | Black |
Power
| Specification | Value |
|---|---|
| Minimum system power supply | 400 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Length | 170 mm |
| Depth | 29.2 mm |
| Height | 114.5 mm |
