GIGABYTE GV-R55XTOC-8GD graphics card AMD Radeon RX 5500 XT

GV-R55XTOC-8GD graphics card AMD Radeon RX 5500 XT

8 GB GDDR6

Model GV-R55XTOC-8GDEAN 889523020517

36 specifications Checked today

TypeFull-Height/Full-Length (FH/FL)
ColourBlack
Graphics processor familyAMD
Discrete graphics card memory8 GB
Interface typePCI Express x16 4.0
DirectX version12.0

See all specifications

Overview

Type: Full-Height/Full-Length (FH/FL)
Colour: Black
Graphics processor family: AMD
Discrete graphics card memory: 8 GB
Interface type: PCI Express x16 4.0
DirectX version: 12.0

Brand: GIGABYTE
Category: GPU
Model: GV-R55XTOC-8GD
Part numbers: GV-R55XTOC-8GD, GVR55XTOC-00-G
EAN / UPC: 889523020517, 4719331306380, 4719331306717
Also known as: GIGABYTE GV-R55XTOC-8GD graphics card AMD Radeon RX 5500 XT 8 GB GDDR6

Specifications

36 specifications in 7 groups

Processor

Specification	Value
Graphics processor family	AMD
Graphics processor	Radeon RX 5500 XT
Maximum resolution	7680 x 4320 pixels
CUDA	No
Processor frequency	1647 MHz
Processor boost clock speed	1845 MHz
Maximum displays per videocard	4
Stream processors	1408

Memory

Specification	Value
Discrete graphics card memory	8 GB
Graphics card memory type	GDDR6
Memory bus	128 bit
Memory clock speed	14000 MHz
Memory bandwidth (max)	224 GB/s

Ports & interfaces

Specification	Value
Interface type	PCI Express x16 4.0
HDMI ports quantity	1
DVI-D ports quantity	0
DVI-I ports quantity	0
DisplayPorts quantity	3
HDMI version	2.0b
DisplayPort version	1.4
VGA (D-Sub) ports quantity	0

Performance

Specification	Value
DirectX version	12.0
OpenGL version	4.6
Dual Link DVI	No
AMD FreeSync	Yes

Design

Specification	Value
Cooling type	Active
Number of fans	2 fan(s)
Fan diameter	9 cm
Bracket height	Full-Height (FH)
Form factor	Full-Height/Full-Length (FH/FL)
Product colour	Black

Power

Specification	Value
Minimum system power supply	450 W
Supplementary power connectors	1x 8-pin

Weight & dimensions

Specification	Value
Length	225 mm
Depth	40 mm
Height	119 mm
