GeForce RTX 2060 WINDFORCE OC
6G
Model GV-N2060WF2OC-6GDPart no. 9VN2060WO6-00-10EAN 889523016190
43 specifications Checked today
- Graphics processor familyNVIDIA
- Discrete graphics card memory6 GB
- Interface typePCI Express x16 3.0
- PhysXYes
- Cooling typeActive
- Minimum system power supply500 W
Overview
- Graphics processor family
- NVIDIA
- Discrete graphics card memory
- 6 GB
- Interface type
- PCI Express x16 3.0
- PhysX
- Yes
- Cooling type
- Active
- Minimum system power supply
- 500 W
- Brand
- GIGABYTE
- Category
- GPU
- Model
- GV-N2060WF2OC-6GD
- Part numbers
- 9VN2060WO6-00-10, GVN2060WO6-00-G2
- EAN / UPC
- 889523016190, 4719331304256, 4719331304393
- Also known as
- GIGABYTE GeForce RTX 2060 WINDFORCE OC 6G
Specifications
43 specifications in 10 groups
Processor
| Specification | Value |
|---|---|
| Graphics processor family | NVIDIA |
| Graphics processor | GeForce RTX 2060 |
| Maximum resolution | 7680 x 4320 pixels |
| CUDA | Yes |
| CUDA cores | 1920 |
| Processor frequency | 1770 MHz |
| FireStream | No |
| Maximum digital resolution | 7680 x 4320 pixels |
| Maximum displays per videocard | 4 |
| Parallel processing technology support | Not supported |
Memory
| Specification | Value |
|---|---|
| Discrete graphics card memory | 6 GB |
| Graphics card memory type | GDDR6 |
| Memory bus | 192 bit |
| Memory clock speed | 14000 MHz |
| Memory bandwidth (max) | 336 GB/s |
Ports & interfaces
| Specification | Value |
|---|---|
| Interface type | PCI Express x16 3.0 |
| HDMI ports quantity | 1 |
| DVI-D ports quantity | 0 |
| DVI-I ports quantity | 0 |
| DisplayPorts quantity | 3 |
| HDMI version | 2.0b |
| DisplayPort version | 1.4 |
| VGA (D-Sub) ports quantity | 0 |
Performance
| Specification | Value |
|---|---|
| PhysX | Yes |
| TV tuner integrated | No |
| DirectX version | 12.0 |
| OpenGL version | 4.5 |
| HDCP | Yes |
| Dual Link DVI | No |
| Full HD | Yes |
Design
| Specification | Value |
|---|---|
| Cooling type | Active |
| Cooling technology | GIGABYTE WINDFORCE 2X |
| Number of fans | 2 fan(s) |
| Number of slots | 2 |
Power
| Specification | Value |
|---|---|
| Minimum system power supply | 500 W |
| Supplementary power connectors | 1x 8-pin |
System requirements
| Specification | Value |
|---|---|
| Windows operating systems supported | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Length | 264.9 mm |
| Depth | 40.4 mm |
| Height | 120.6 mm |
Packaging data
| Specification | Value |
|---|---|
| Package type | Box |
Packaging content
| Specification | Value |
|---|---|
| Drivers included | Yes |
| User guide | Yes |
