GIGABYTE Geforce RTX 2060 MINI ITX OC

Geforce RTX 2060 MINI ITX OC

6G

Model GV-N2060IXOC-6GDPart no. 9VN2060IO6-00-10EAN 4719331304270

41 specifications Checked today

Graphics processor familyNVIDIA
Discrete graphics card memory6 GB
Interface typePCI Express x16 3.0
PhysXYes
Cooling typeActive
Minimum system power supply500 W

See all specifications

Overview

Graphics processor family: NVIDIA
Discrete graphics card memory: 6 GB
Interface type: PCI Express x16 3.0
PhysX: Yes
Cooling type: Active
Minimum system power supply: 500 W

Brand: GIGABYTE
Category: GPU
Model: GV-N2060IXOC-6GD
Part number: 9VN2060IO6-00-10
EAN / UPC: 4719331304270, 4719331304409
Also known as: GIGABYTE Geforce RTX 2060 MINI ITX OC 6G

Specifications

41 specifications in 10 groups

Processor

Specification	Value
Graphics processor family	NVIDIA
Graphics processor	GeForce RTX 2060
Maximum resolution	7680 x 4320 pixels
CUDA	Yes
CUDA cores	1920
Processor frequency	1695 MHz
FireStream	No
Maximum digital resolution	7680 x 4320 pixels
Maximum displays per videocard	4
Parallel processing technology support	Not supported

Memory

Specification	Value
Discrete graphics card memory	6 GB
Graphics card memory type	GDDR6
Memory bus	192 bit
Memory clock speed	14000 MHz
Memory bandwidth (max)	336 GB/s

Ports & interfaces

Specification	Value
Interface type	PCI Express x16 3.0
HDMI ports quantity	1
DVI-D ports quantity	0
DVI-I ports quantity	0
DisplayPorts quantity	3
HDMI version	2.0b
DisplayPort version	1.4
VGA (D-Sub) ports quantity	0

Performance

Specification	Value
PhysX	Yes
TV tuner integrated	No
DirectX version	12.0
OpenGL version	4.5
HDCP	Yes
Full HD	Yes

Design

Specification	Value
Cooling type	Active
Number of fans	1 fan(s)
Number of slots	2

Power

Specification	Value
Minimum system power supply	500 W
Supplementary power connectors	1x 8-pin

System requirements

Specification	Value
Windows operating systems supported	Yes

Weight & dimensions

Specification	Value
Length	170 mm
Depth	36.4 mm
Height	121.3 mm

Packaging data

Specification	Value
Package type	Box

Packaging content

Specification	Value
Drivers included	Yes
User guide	Yes
