GeForce RTX 4070 Ti SUPER WINDFORCE MAX OC 16G
Model GeForce RTX 4070 Ti SUPER WINDFORCE MAX OC 16GPart no. GV-N407TSWF3MAX OC-16GDEAN 4719331354671
53 specifications Checked today
- TypeFull-Height/Full-Length (FH/FL)
- Weight1.2 kg
- ColourBlack
- Graphics processor familyNVIDIA
- Discrete graphics card memory16 GB
- Interface typePCI Express x16 4.0
Overview
- Type
- Full-Height/Full-Length (FH/FL)
- Weight
- 1.2 kg
- Colour
- Black
- Graphics processor family
- NVIDIA
- Discrete graphics card memory
- 16 GB
- Interface type
- PCI Express x16 4.0
- Brand
- GIGABYTE
- Category
- GPU
- Model
- GeForce RTX 4070 Ti SUPER WINDFORCE MAX OC 16G
- Part number
- GV-N407TSWF3MAX OC-16GD
- EAN / UPC
- 4719331354671
- Also known as
- GIGABYTE GeForce RTX 4070 Ti SUPER WINDFORCE MAX OC Graphics Card - 16GB GDDR6X, 256bit, PCI-E 4.0, 2655MHz Core Clock, 3 x DisplayPort 1.4a, 1 x HDMI 2.1a, NVI
Specifications
53 specifications in 11 groups
Processor
| Specification | Value |
|---|---|
| Graphics processor family | NVIDIA |
| Graphics processor | GeForce RTX 4070 Ti SUPER |
| Maximum resolution | 7680 x 4320 pixels |
| CUDA | Yes |
| CUDA cores | 8448 |
| Processor frequency | 2655 MHz |
| Maximum displays per videocard | 4 |
| Parallel processing technology support | Not supported |
Memory
| Specification | Value |
|---|---|
| Discrete graphics card memory | 16 GB |
| Graphics card memory type | GDDR6X |
| Memory bus | 256 bit |
| Memory clock speed | 21000 MHz |
| Number of pipelines | 9 |
| Data transfer rate | 21 Gbit/s |
Ports & interfaces
| Specification | Value |
|---|---|
| Interface type | PCI Express x16 4.0 |
| HDMI ports quantity | 1 |
| DVI-D ports quantity | 0 |
| DVI-I ports quantity | 0 |
| DisplayPorts quantity | 3 |
| HDMI version | 2.1a |
| DisplayPort version | 1.4a |
Performance
| Specification | Value |
|---|---|
| TV tuner integrated | No |
| DirectX version | 12 Ultimate |
| OpenGL version | 4.6 |
| Dual Link DVI | No |
| NVIDIA G-SYNC | Yes |
| Overclocked (OC) edition | Yes |
| Warranty period | 3 year(s) |
Design
| Specification | Value |
|---|---|
| Cooling type | Active |
| Cooling technology | GIGABYTE WINDFORCE 3X |
| Number of fans | 3 fan(s) |
| Fan diameter | 10 cm |
| Bracket height | Full-Height (FH) |
| Form factor | Full-Height/Full-Length (FH/FL) |
| Number of slots | 2 |
| Illumination | No |
| SFF ready | No |
| Product colour | Black |
Power
| Specification | Value |
|---|---|
| Minimum system power supply | 750 W |
| Supplementary power connectors | 1x 16-pin |
System requirements
| Specification | Value |
|---|---|
| Windows operating systems supported | Windows 10 x64, Windows 11 x64 |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 1.2 kg |
| Length | 201 mm |
| Depth | 41 mm |
| Height | 120 mm |
Packaging data
| Specification | Value |
|---|---|
| Package width | 230 mm |
| Package depth | 398 mm |
| Package height | 85 mm |
| Package weight | 2.13 kg |
| Package type | Box |
Packaging content
| Specification | Value |
|---|---|
| Quick installation guide | Yes |
Logistics data
| Specification | Value |
|---|---|
| Country of origin | China |
| Products per shipping (inner) case | 1 pc(s) |
