ASUS Dual -RTX2070S-O8G-EVO NVIDIA GeForce RTX 2070 SUPER

Dual -RTX2070S-O8G-EVO NVIDIA GeForce RTX 2070 SUPER

8 GB GDDR6

Model DUAL-RTX2070S-O8G-EVOPart no. 90YV0DK0-M0NA00EAN 4718017421331

35 specifications Checked today

Graphics processor familyNVIDIA
Discrete graphics card memory8 GB
Interface typePCI Express 3.0
OpenGL version4.6
Cooling typeActive
Minimum system power supply650 W

See all specifications

Overview

Graphics processor family: NVIDIA
Discrete graphics card memory: 8 GB
Interface type: PCI Express 3.0
OpenGL version: 4.6
Cooling type: Active
Minimum system power supply: 650 W

Brand: ASUS
Category: GPU
Model: DUAL-RTX2070S-O8G-EVO
Part numbers: 90YV0DK0-M0NA00, DUAL-RTX2070S-O8G-EVO
EAN / UPC: 4718017421331
Also known as: ASUS Dual -RTX2070S-O8G-EVO NVIDIA GeForce RTX 2070 SUPER 8 GB GDDR6

Specifications

35 specifications in 8 groups

Processor

Specification	Value
Graphics processor family	NVIDIA
Graphics processor	GeForce RTX 2070 SUPER
Maximum resolution	7680 x 4320 pixels
CUDA	Yes
CUDA cores	2560
Processor frequency (OC mode)	1635 MHz
Processor boost clock speed (OC mode)	1845 MHz
FireStream	No
Maximum displays per videocard	4
Parallel processing technology support	NVLink

Memory

Specification	Value
Discrete graphics card memory	8 GB
Graphics card memory type	GDDR6
Memory bus	256 bit

Ports & interfaces

Specification	Value
Interface type	PCI Express 3.0
HDMI ports quantity	1
DVI-D ports quantity	0
DVI-I ports quantity	0
DisplayPorts quantity	3
HDMI version	2.0b
DisplayPort version	1.4
USB Type-C ports quantity	1
VGA (D-Sub) ports quantity	0

Performance

Specification	Value
OpenGL version	4.6
Virtual Reality (VR) ready	Yes
HDCP	Yes
NVIDIA G-SYNC	Yes

Design

Specification	Value
Cooling type	Active
Number of fans	2 fan(s)
Number of slots	2.7

Power

Specification	Value
Minimum system power supply	650 W
Supplementary power connectors	1x 6-pin, 1x 8-pin

Weight & dimensions

Specification	Value
Length	267 mm
Depth	58 mm
Height	118 mm

Packaging content

Specification	Value
Bundled software	ASUS GPU Tweak II & Driver
