ELP-DC06 document camera White 25.4
3 mm (1 / 3") CMOS USB 2.0
Model ELP-DC06Part no. V12H321003EAN 8715946460475
40 specifications
- ConnectivityUSB 2.0
- Weight900 g
- ColourWhite
- Effective sensor resolution1.92 MP
- Maximum focal length (f)4.1 mm
- Power consumption (typical)2.5 W
Overview
- Connectivity
- USB 2.0
- Weight
- 900 g
- Colour
- White
- Effective sensor resolution
- 1.92 MP
- Maximum focal length (f)
- 4.1 mm
- Power consumption (typical)
- 2.5 W
- Brand
- Epson
- Category
- Document Camera
- Model
- ELP-DC06
- Part numbers
- V12H321003, V12H321001
- EAN / UPC
- 8715946460475, 010343873469, 5052916498575, 5054484151814 +1 more
- Also known as
- Epson ELP-DC06 document camera White 25.4 / 3 mm (1 / 3") CMOS USB 2.0
Specifications
40 specifications in 9 groups
Camera
| Specification | Value |
|---|---|
| Effective sensor resolution | 1.92 MP |
| Optical sensor size | 25.4 / 3 mm (1 / 3") |
| Sensor type | CMOS |
| Supported graphics resolutions | 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1600 x 1200 (UXGA), 320 x 288 (QVGA), 640 x 480 (VGA), 800 x 600 (SVGA) |
| Maximum frame rate | 15 fps |
| White balance | Auto |
| Light exposure modes | Auto |
| Image freeze | Yes |
| Light source | LED |
Lens system
| Specification | Value |
|---|---|
| Maximum focal length (f) | 4.1 mm |
| Auto focus | Yes |
| Digital zoom | 4x |
| Shooting area (WxD) | 271.8 x 363.2 mm |
| Iris | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Interface | USB 2.0 |
| USB connector type | USB Type-B |
Technical details
| Specification | Value |
|---|---|
| Product colour | White |
| Horizontal rotation angle | -90 - 90° |
| Vertical rotation angle | -90 - 90° |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 2.5 W |
| USB powered | Yes |
| Operating voltage | 5 V |
| Power consumption | 500 mA |
System requirements
| Specification | Value |
|---|---|
| Windows operating systems supported | Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate x64, Windows XP Home, Windows XP Professional |
| Mac operating systems supported | No |
| Minimum RAM | 512 MB |
| Minimum storage drive space | 300 MB |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 35 °C |
| Operating relative humidity (H-H) | 20 - 80% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 260 mm |
| Depth | 76 mm |
| Height | 60 mm |
| Weight | 900 g |
| Dimensions folded (WxDxH) | 260 x 76 x 60 mm |
Packaging content
| Specification | Value |
|---|---|
| Cables included | USB |
| Carrying case | Yes |
| Manual | Yes |
| User guide | Yes |
