M70-HD document camera Black 25.4
3.2 mm (1 / 3.2") CMOS USB 2.0
Model M70-HDPart no. 61P0H3P000BJEAN 848090004283
69 specifications
- ConnectivityUSB 2.0
- Weight6.75 kg
- ColourBlack
- Effective sensor resolution5 MP
- Auto focusYes
- Document size (max)A3
Overview
- Connectivity
- USB 2.0
- Weight
- 6.75 kg
- Colour
- Black
- Effective sensor resolution
- 5 MP
- Auto focus
- Yes
- Document size (max)
- A3
- Brand
- AVer
- Category
- Document Camera
- Model
- M70-HD
- Part number
- 61P0H3P000BJ
- EAN / UPC
- 848090004283, 4054842092606, 4719552123438
- Also known as
- AVer M70-HD document camera Black 25.4 / 3.2 mm (1 / 3.2") CMOS USB 2.0
Specifications
69 specifications in 11 groups
Camera
| Specification | Value |
|---|---|
| Effective sensor resolution | 5 MP |
| Optical sensor size | 25.4 / 3.2 mm (1 / 3.2") |
| Sensor type | CMOS |
| Supported graphics resolutions | 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1600 x 900, 1920 x 1080 (HD 1080) |
| HD type | Full HD |
| Maximum video resolution | 1920 x 1080 pixels |
| Video recording | Yes |
| Maximum frame rate | 30 fps |
| White balance | Auto, Manual |
| Light exposure modes | Auto, Manual |
| Image freeze | Yes |
| Continuous shooting mode | Yes |
| Light source | LED |
Lens system
| Specification | Value |
|---|---|
| Auto focus | Yes |
| Optical zoom | 12x |
| Digital zoom | 8x |
| Shooting area (WxD) | 420 x 297 mm |
Ports & interfaces
| Specification | Value |
|---|---|
| Interface | USB 2.0 |
| HDMI input ports quantity | 1 |
| HDMI output ports quantity | 1 |
| USB connector type | USB Type-A |
| Audio output | Yes |
| Composite video out | 1 |
| DC-in jack | Yes |
| RS-232 ports | 1 |
| USB 2.0 ports quantity | 2 |
| VGA (D-Sub) output ports | 1 |
Storage
| Specification | Value |
|---|---|
| Card reader integrated | Yes |
| Compatible memory cards | SDHC |
| Maximum memory card size | 32 GB |
| Memory capacity (images) | 240 |
Technical details
| Specification | Value |
|---|---|
| Document size (max) | A3 |
| Product colour | Black |
| Control type | Buttons |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Annotation | Yes |
| Built-in microphone | Yes |
| Camera movement | Manual |
| Country of origin | Taiwan |
| Image quality adjustment | Sharpness |
| Lamp type | LED |
| Photo effects | Mirror, Negative film |
| Zoom capability | Yes |
Power
| Specification | Value |
|---|---|
| Power supply type | DC |
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 100-240 V |
System requirements
| Specification | Value |
|---|---|
| Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 |
| Mac compatibility | Yes |
| Mac operating systems supported | Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 428 mm |
| Depth | 252 mm |
| Height | 166 mm |
| Weight | 6.75 kg |
| Dimensions folded (WxDxH) | 182 x 63 x 388 mm |
Packaging data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
| Package width | 366 mm |
| Package depth | 280 mm |
| Package height | 448 mm |
| Package weight | 7.62 kg |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Remote control included | Yes |
| Remote control batteries included | Yes |
| Cables included | Mini-USB, VGA |
| Manual | No |
| User guide | Yes |
| Warranty card | Yes |
Logistics data
| Specification | Value |
|---|---|
| Products per master (outer) case | 2 pc(s) |
| Products per pallet | 50 pc(s) |
