M15-13M document camera Black 25.4
3.06 mm (1 / 3.06") CMOS USB 2.0
Model M15-13MPart no. 61PM020000AEEAN 4719552125791
41 specifications
- ConnectivityUSB 2.0
- Weight680 g
- ColourBlack
- Effective sensor resolution13 MP
- Auto focusYes
- Document size (max)A3
Overview
- Connectivity
- USB 2.0
- Weight
- 680 g
- Colour
- Black
- Effective sensor resolution
- 13 MP
- Auto focus
- Yes
- Document size (max)
- A3
- Brand
- AVer
- Category
- Document Camera
- Model
- M15-13M
- Part number
- 61PM020000AE
- EAN / UPC
- 4719552125791
- Also known as
- AVer M15-13M document camera Black 25.4 / 3.06 mm (1 / 3.06") CMOS USB 2.0
Specifications
41 specifications in 10 groups
Camera
| Specification | Value |
|---|---|
| Effective sensor resolution | 13 MP |
| Optical sensor size | 25.4 / 3.06 mm (1 / 3.06") |
| Sensor type | CMOS |
| Maximum frame rate | 60 fps |
| White balance | Auto, Manual |
| Light exposure modes | Auto, Manual |
| Image freeze | Yes |
| Light source | LED |
Lens system
| Specification | Value |
|---|---|
| Auto focus | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Interface | USB 2.0 |
| HDMI output ports quantity | 1 |
| USB connector type | Mini-USB B |
| DC-in jack | Yes |
Technical details
| Specification | Value |
|---|---|
| Document size (max) | A3 |
| Product colour | Black |
| Horizontal rotation angle | 0 - 180° |
| Built-in microphone | Yes |
| Country of origin | Taiwan |
| Photo effects | Black&White, Negative film |
| Zoom capability | Yes |
Power
| Specification | Value |
|---|---|
| Power supply type | AC |
| Power consumption (typical) | 4 W |
| AC input voltage | 100-240 V |
System requirements
| Specification | Value |
|---|---|
| Windows operating systems supported | Windows 10, Windows 8, Windows 8.1 |
| Mac compatibility | Yes |
| Mac operating systems supported | Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 11.0 Big Sur |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 84 mm |
| Depth | 280 mm |
| Height | 42 mm |
| Weight | 680 g |
| Dimensions folded (WxDxH) | 84 x 280 x 42 mm |
Packaging data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
| Package width | 143 mm |
| Package depth | 366 mm |
| Package height | 136 mm |
| Package weight | 1.4 kg |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Cables included | USB |
| User guide | Yes |
Logistics data
| Specification | Value |
|---|---|
| Products per master (outer) case | 4 pc(s) |
| Products per pallet | 160 pc(s) |
