M11-8MV document camera Black 25.4
3.06 mm (1 / 3.06") CMOS USB 2.0
Model M11-8MVPart no. 61PM030000ACEAN 4719552125937
42 specifications
- ConnectivityUSB 2.0
- Weight830 g
- ColourBlack
- Effective sensor resolution8 MP
- Digital zoom20x
- Card reader integratedYes
Overview
- Connectivity
- USB 2.0
- Weight
- 830 g
- Colour
- Black
- Effective sensor resolution
- 8 MP
- Digital zoom
- 20x
- Card reader integrated
- Yes
- Brand
- AVer
- Category
- Document Camera
- Model
- M11-8MV
- Part number
- 61PM030000AC
- EAN / UPC
- 4719552125937
- Also known as
- AVer M11-8MV document camera Black 25.4 / 3.06 mm (1 / 3.06") CMOS USB 2.0
Specifications
42 specifications in 11 groups
Camera
| Specification | Value |
|---|---|
| Effective sensor resolution | 8 MP |
| Optical sensor size | 25.4 / 3.06 mm (1 / 3.06") |
| Sensor type | CMOS |
| Supported graphics resolutions | 1920 x 1080 (HD 1080) |
| Maximum frame rate | 60 fps |
| White balance | Auto, Manual |
| Light exposure modes | Auto, Manual |
| Light source | LED |
Lens system
| Specification | Value |
|---|---|
| Digital zoom | 20x |
Ports & interfaces
| Specification | Value |
|---|---|
| Interface | USB 2.0 |
| HDMI output ports quantity | 1 |
| USB connector type | Mini-USB, USB Type-A |
| USB 2.0 ports quantity | 1 |
| VGA (D-Sub) output ports | 1 |
Storage
| Specification | Value |
|---|---|
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash) |
| Maximum memory card size | 32 GB |
Technical details
| Specification | Value |
|---|---|
| Document size (max) | A3 |
| Product colour | Black |
| Horizontal rotation angle | 0 - 180° |
| Built-in microphone | Yes |
| Country of origin | Taiwan |
| Photo effects | Black&White, Negative film |
Power
| Specification | Value |
|---|---|
| Power supply type | USB |
| USB powered | Yes |
| Operating voltage | 5 V |
System requirements
| Specification | Value |
|---|---|
| Windows operating systems supported | Windows 10, Windows 7 |
| Mac compatibility | Yes |
| Mac operating systems supported | Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 11.0 Big Sur |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 116.7 mm |
| Depth | 143.1 mm |
| Height | 296.1 mm |
| Weight | 830 g |
| Dimensions folded (WxDxH) | 116.7 x 143.1 x 296.1 mm |
Packaging data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
| Package width | 152 mm |
| Package depth | 362 mm |
| Package height | 144 mm |
| Package weight | 1.3 kg |
Packaging content
| Specification | Value |
|---|---|
| Cables included | USB |
Logistics data
| Specification | Value |
|---|---|
| Products per master (outer) case | 2 pc(s) |
| Products per pallet | 120 pc(s) |
