KMM-DAB403 Black
200 W
Model KMM-DAB403Part no. KMM-DAB403A0EAN 019048229304
49 specifications
- Weight600 g
- ColourBlack
- MP3 playbackYes
- BluetoothNo
- Preset stations quantity24
- Width182 mm
Overview
- Weight
- 600 g
- Colour
- Black
- MP3 playback
- Yes
- Bluetooth
- No
- Preset stations quantity
- 24
- Width
- 182 mm
- Brand
- Kenwood
- Category
- Car Media Receiver
- Model
- KMM-DAB403
- Part number
- KMM-DAB403A0
- EAN / UPC
- 019048229304
- Also known as
- Kenwood KMM-DAB403 Black 200 W
Specifications
49 specifications in 7 groups
Performance
| Specification | Value |
|---|---|
| Product colour | Black |
| DIN size | 1 DIN |
| Output power | 200 W |
| Maximum power per channel | 50 W |
| Disc types supported | No |
| Ready for iPod | Yes |
| iPod connectivity | Yes |
| Bass adjustment | Yes |
| Low pass filter | Yes |
| Volume control | Rotary |
| Equalizer | Yes |
| Equalizer bands quantity | 3 |
| Clock mode | 24h |
| Integrated clock | Yes |
| Firmware upgradeable | Yes |
Multimedia
| Specification | Value |
|---|---|
| MP3 playback | Yes |
| USB direct playback | Yes |
| CD-R playback | No |
| Audio formats supported | FLAC, MP3, WAV, WMA |
Display
| Specification | Value |
|---|---|
| Built-in display | Yes |
| Display type | LCD |
| Display digits | 13 digits |
| Display illumination | Yes |
| Illumination colour | White |
| Detachable display | Yes |
| ID3 Tag display | Yes |
| On Screen Display (OSD) | Yes |
| On Screen Display (OSD) languages | English, Spanish, Greek, Russian |
Ports & interfaces
| Specification | Value |
|---|---|
| Bluetooth | No |
| ISO connector | Yes |
| USB port | Yes |
| USB ports quantity | 1 |
| USB version | 2.0 |
| USB connector type | USB Type-A |
| USB port position | Front |
| AUX in | Yes |
| Line outputs (RCA) | 1 |
Radio
| Specification | Value |
|---|---|
| Preset stations quantity | 24 |
| Supported radio bands | AM, DAB+, FM, LW, MW |
| FM band range | 87.5 - 108 MHz |
| AM band range | 531 - 1611 kHz |
| LW band range | 153 - 279 kHz |
| Radio Data System (RDS) | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 182 mm |
| Depth | 158 mm |
| Height | 53 mm |
| Weight | 600 g |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -10 - 60 °C |
| Storage temperature (T-T) | -30 - 85 °C |
