KDC-110UG car media receiver Black, Green
200 W
Model KDC-110UGEAN 019048216786
79 specifications
- Weight1.3 kg
- ColourBlack, Green
- MP3 playbackYes
- BluetoothNo
- Preset stations quantity24
- Output power (DIN)88 W
Overview
- Weight
- 1.3 kg
- Colour
- Black, Green
- MP3 playback
- Yes
- Bluetooth
- No
- Preset stations quantity
- 24
- Output power (DIN)
- 88 W
- Brand
- Kenwood
- Category
- Car Media Receiver
- Model
- KDC-110UG
- Part number
- KDC-110UG
- EAN / UPC
- 019048216786
- Also known as
- Kenwood KDC-110UG car media receiver Black, Green 200 W
Specifications
79 specifications in 10 groups
Performance
| Specification | Value |
|---|---|
| Product colour | Black, Green |
| DIN size | 1 DIN |
| Output power | 200 W |
| Audio output channels | 4.0 channels |
| Maximum power per channel | 50 W |
| Frequency range | 20 - 20000 Hz |
| Signal-to-Noise Ratio (SNR) | 105 dB |
| Impedance | 75 Ω |
| CD player | Yes |
| Disc types supported | CD, CD-R, CD-RW |
| Mobile operating systems supported | Android |
| Bass adjustment | Yes |
| Low pass filter | Yes |
| Volume control | Rotary |
| Equalizer | Yes |
| Equalizer bands quantity | 3 |
| Equalizer customizable | Yes |
| Removable front panel | Yes |
| Clock mode | 24h |
| Integrated clock | Yes |
| RDS features | EON, PTY |
| Dimmer | Yes |
| Firmware upgradeable | Yes |
Multimedia
| Specification | Value |
|---|---|
| MP3 playback | Yes |
| USB direct playback | Yes |
| CD-R playback | Yes |
| CD-RW playback | Yes |
| Audio D/A Converter (DAC) | 16 bit |
| Audio formats supported | FLAC, MP3, WAV, WMA |
Display
| Specification | Value |
|---|---|
| Built-in display | Yes |
| Display type | LCD |
| Display digits | 13 digits |
| Display illumination | Yes |
| Illumination colour | White |
| ID3 Tag display | Yes |
| Number of OSD languages | 4 |
| On Screen Display (OSD) | Yes |
| On Screen Display (OSD) languages | English, Spanish, Greek, Russian |
| CD Text | Yes |
| LED backlight | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Bluetooth | No |
| ISO connector | Yes |
| USB port | Yes |
| USB ports quantity | 1 |
| USB version | 2.0 |
| USB connector type | USB Type-A |
| USB port position | Front |
| Illuminated USB port | Yes |
| AUX in | Yes |
| Line outputs (RCA) | 1 |
| Pre out port | Yes |
| Subwoofer out | Yes |
Radio
| Specification | Value |
|---|---|
| Preset stations quantity | 24 |
| Supported radio bands | AM, FM, LW, MW |
| FM band range | 87.5 - 108 MHz |
| AM band range | 531 - 1611 kHz |
| LW band range | 153 - 279 kHz |
| Radio Data System (RDS) | Yes |
| Auto digital tuning | Yes |
| FM radio | Yes |
Power
| Specification | Value |
|---|---|
| Output power (DIN) | 88 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 182 mm |
| Depth | 158 mm |
| Height | 53 mm |
| Dimensions (WxDxH) | 182 x 158 x 53 mm |
| Weight | 1.3 kg |
Technical details
| Specification | Value |
|---|---|
| Output voltage | 14.4 V |
| Antenna | Yes |
| Disc playback modes | Random, Repeat track |
| Fader | Yes |
| File format system | FAT 12/16/32 |
| Filtering | Yes |
| Key illumination colour | Green |
| Playback disc types | CD, CD-R, CD-RW |
| Playback modes | Next, Normal, Pause, Previous, Random, Repeat |
| Tuner enhancements | Auto scan, Auto tuning |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -10 - 60 °C |
Packaging content
| Specification | Value |
|---|---|
| Cables included | DC |
| IFU / User manual | Yes |
