KD-X152 car media receiver Black, Silver
200 W
Model KD-X152EAN 4975769449703
93 specifications
- Weight600 g
- ColourBlack, Silver
- MP3 playbackYes
- BluetoothNo
- Preset stations quantity24
- Output power (DIN)4x 22 W
Overview
- Weight
- 600 g
- Colour
- Black, Silver
- MP3 playback
- Yes
- Bluetooth
- No
- Preset stations quantity
- 24
- Output power (DIN)
- 4x 22 W
- Brand
- JVC
- Category
- Car Media Receiver
- Model
- KD-X152
- Part number
- KD-X152
- EAN / UPC
- 4975769449703
- Also known as
- JVC KD-X152 car media receiver Black, Silver 200 W
Specifications
93 specifications in 10 groups
Performance
| Specification | Value |
|---|---|
| Product colour | Black, Silver |
| DIN size | 1 DIN |
| Output power | 200 W |
| Audio output channels | 4.1 channels |
| Maximum power per channel | 50 W |
| Frequency range | 20 - 20000 Hz |
| Signal-to-Noise Ratio (SNR) | 105 dB |
| Impedance | 75 Ω |
| CD player | No |
| Disc types supported | No |
| Mobile operating systems supported | Android, Android 4.1, Android 4.2, Android 4.2.1, Android 4.3, Android 4.4, Android 5.0, Android 5.1, Android 6.0, Android 7.1 |
| Ready for iPod | No |
| Bass adjustment | Yes |
| Low pass filter | Yes |
| Smartphone/tablet remote support | Yes |
| Volume control | Rotary |
| Equalizer | Yes |
| Equalizer bands quantity | 3 |
| Equalizer customizable | Yes |
| Removable front panel | Yes |
| Clock mode | 12h/24h |
| Integrated clock | Yes |
| RDS features | AF, CT, PS, PTY, PTY1, REG, RT, TI |
| Dimmer | Yes |
| Firmware upgradeable | Yes |
| Steering mounting remote control capability | Yes |
Multimedia
| Specification | Value |
|---|---|
| MP3 playback | Yes |
| USB direct playback | Yes |
| CD-R playback | No |
| CD-RW playback | No |
| Built-in audio D/A Converter (DAC) | Yes |
| Audio D/A Converter (DAC) | 24 bit |
| Audio formats supported | FLAC, MP3, PCM, WAV, WMA |
Display
| Specification | Value |
|---|---|
| Built-in display | Yes |
| Display type | LCD |
| Display number of lines | 2 lines |
| Display illumination | Yes |
| Illumination colour | White |
| Detachable display | Yes |
| ID3 Tag display | Yes |
| Number of OSD languages | 3 |
| On Screen Display (OSD) | Yes |
| On Screen Display (OSD) languages | English, Spanish, Russian |
| LED backlight | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Bluetooth | No |
| ISO connector | Yes |
| USB port | Yes |
| USB ports quantity | 1 |
| USB version | 2.0 |
| USB connector type | USB Type-A |
| USB port position | Front |
| Illuminated USB port | Yes |
| Android Auto support | Yes |
| AUX in | Yes |
| Headphone connectivity | 3.5mm |
| Line outputs (RCA) | 1 |
| Pre out port | Yes |
| Subwoofer out | Yes |
Radio
| Specification | Value |
|---|---|
| Preset stations quantity | 24 |
| Supported radio bands | AM, FM, LW, MW |
| FM band range | 87.5 - 108 MHz |
| AM band range | 531 - 1611 kHz |
| LW band range | 153 - 279 kHz |
| Radio Data System (RDS) | Yes |
| Auto digital tuning | Yes |
| FM radio | Yes |
Power
| Specification | Value |
|---|---|
| Output power (DIN) | 4x 22 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Dimensions (WxDxH) | 182 x 100 x 53 mm |
| Weight | 600 g |
Technical details
| Specification | Value |
|---|---|
| Output voltage | 14.4 V |
| USB mass storage | Yes |
| Antenna | Yes |
| Fader | Yes |
| File format system | FAT 12/16/32 |
| Filtering | Yes |
| Key illumination colour | Red |
| Menu languages | English, Spanish, Russian |
| Pause function | Yes |
| Platform | Android |
| Playback modes | Fast Backward, Fast forward, Fast reverse, Folder, Hold, Next, Normal, Pause, Play, Previous, Random, Repeat, Repeat all, Repeat folder, Repeat one, Stop, Title once |
| Position indicator | Yes |
| Power requirements | DC 5V 1A |
| Pre-out channels | 2 SW |
| RMS rated power | 88 W |
| Repeatability | Yes |
| Reverse connection | Yes |
| Security features | Removable front |
| Signal strength indication | Yes |
| Treble adjustment | Yes |
| Tuner enhancements | Auto scan, Auto tuning |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -10 - 60 °C |
| Storage temperature (T-T) | -30 - 85 °C |
Packaging content
| Specification | Value |
|---|---|
| Mounting brackets included | Yes |
