DMX7722DABCAMPER car media receiver Black Wi-Fi
88 W Bluetooth
Model DMX7722DABCAMPEREAN 4029623088932
62 specifications
- Display17.3 cm (6.8")
- Resolution800 x 480 pixels
- Weight1.2 kg
- ColourBlack
- MP3 playbackYes
- Tuner typeJKTS
Overview
- Display
- 17.3 cm (6.8")
- Resolution
- 800 x 480 pixels
- Weight
- 1.2 kg
- Colour
- Black
- MP3 playback
- Yes
- Tuner type
- JKTS
- Brand
- Kenwood
- Category
- Car Media Receiver
- Model
- DMX7722DABCAMPER
- Part number
- DMX7722DABCAMPER
- EAN / UPC
- 4029623088932
- Also known as
- Kenwood DMX7722DABCAMPER car media receiver Black Wi-Fi 88 W Bluetooth
Specifications
62 specifications in 9 groups
Performance
| Specification | Value |
|---|---|
| Product colour | Black |
| DIN size | 2 DIN |
| Output power | 88 W |
| Audio output channels | 4.0 channels |
| Maximum power per channel | 50 W |
| Frequency range | 20 - 88000 Hz |
| Impedance | 600 Ω |
| Disc types supported | No |
| Ready for iPod | Yes |
| iPod connectivity | Yes |
| High pass filter | Yes |
| Low pass filter | Yes |
| Volume control | Touch |
| Equalizer | Yes |
| Equalizer bands quantity | 13 |
| Clock mode | 24h |
| Integrated clock | Yes |
| Customizable GUI | Yes |
| Dimmer | Yes |
Multimedia
| Specification | Value |
|---|---|
| MP3 playback | Yes |
| USB direct playback | Yes |
| CD-R playback | No |
| Audio formats supported | AAC, FLAC, MP3, WAV, WMA |
| Image formats supported | BMP, JPEG, PNG |
| Video formats supported | H.264, MKV, MPEG1, MPEG2, MPEG4, WMV |
Display
| Specification | Value |
|---|---|
| Built-in display | Yes |
| Display type | LCD |
| Touchscreen | Yes |
| Touchscreen type | Capacitive |
| Display diagonal | 17.3 cm (6.8") |
| Display resolution | 800 x 480 pixels |
| Brightness adjustment | Yes |
| Number of OSD languages | 14 |
| On Screen Display (OSD) languages | Czech, German, Dutch, English, Spanish, French, Greek, Hebrew, Hungarian, Italian, Polish, Portuguese, Russian |
| LED backlight | Yes |
| Rear-view camera ready | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Wi-Fi | Yes |
| Bluetooth | Yes |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| USB port | Yes |
| USB version | 2.0 |
| USB port position | Rear |
| Apple CarPlay support | Yes |
| Android Auto support | Yes |
| AV input | Yes |
| Headphone connectivity | 3.5mm |
| Line outputs (RCA) | 3 |
| Microphone in | Yes |
Radio
| Specification | Value |
|---|---|
| Tuner type | JKTS |
| Preset stations quantity | 20 |
| Supported radio bands | AM, DAB, DAB+, FM |
| DAB tuner | Yes |
GPS Performance
| Specification | Value |
|---|---|
| GPS (satellite) | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 182 mm |
| Depth | 74 mm |
| Height | 111 mm |
| Weight | 1.2 kg |
Memory
| Specification | Value |
|---|---|
| Card reader integrated | No |
Packaging content
| Specification | Value |
|---|---|
| Manual | Yes |
| Cables included | Audio (3.5mm), DC |
| Quick start guide | Yes |
