JVC KW-M593BT car media receiver Black Wi-Fi: Full Specifications

Overview

Display: 17.3 cm (6.8")
Resolution: 1024 x 600 pixels
Weight: 1.27 kg
Colour: Black
MP3 playback: Yes
Tuner type: JKTS

Brand: JVC
Category: Car Media Receiver
Model: KW-M593BT
Part number: KW-M593BT
EAN / UPC: 4975769478857
Also known as: JVC KW-M593BT car media receiver Black Wi-Fi 22 W Bluetooth

Specifications

53 specifications in 8 groups

Performance

Specification	Value
Product colour	Black
Output power	22 W
Frequency range	20 - 20000 Hz
Impedance	4 Ω
Disc types supported	No
Analog signal format system	NTSC, PAL
Ready for iPod	Yes
Customizable GUI	Yes
Dimmer	Yes
Time alignment	Yes

Multimedia

Specification	Value
MP3 playback	Yes
USB direct playback	Yes
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	BMP, JPEG, PNG
Video formats supported	H.264, MKV, MPEG1, MPEG2, MPEG4, WMV

Display

Specification	Value
Built-in display	Yes
Display type	LED
Touchscreen	Yes
Touchscreen type	Capacitive
Display diagonal	17.3 cm (6.8")
Display resolution	1024 x 600 pixels
Display illumination	Yes
Number of OSD languages	14
On Screen Display (OSD)	Yes
On Screen Display (OSD) languages	Czech, German, Dutch, English, Spanish, French, Greek, Hebrew, Hungarian, Italian, Polish, Portuguese, Russian
LED backlight	Yes

Ports & interfaces

Specification	Value
Wi-Fi	Yes
Bluetooth	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Wi-Fi frequency	2.4 GHz
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Bluetooth version	5.0
Bluetooth profiles	A2DP, AAC, AVRCP, HPF, PBAP, SBC
USB port	Yes
USB ports quantity	1
USB version	2.0
Apple CarPlay support	Yes
Android Auto support	Yes
Pre out port	Yes

Radio

Specification	Value
Tuner type	JKTS
Preset stations quantity	36
Supported radio bands	DAB+, FM, LW, MW
FM band range	87.5 - 108 MHz
AM band range	531 - 1611 kHz
Radio Data System (RDS)	Yes
Automatic presetting	Yes
DAB tuner	DAB+

Call management

Specification	Value
Hands-free calling	Yes

Weight & dimensions

Specification	Value
Width	182 mm
Depth	86 mm
Height	112 mm
Weight	1.27 kg

Memory

Specification	Value
Card reader integrated	No
