A-S500 2.0 channels Home Black
Model A-S500Part no. A-S500BEAN 4957812481922
28 specifications
- ConnectivityWired
- Weight10.2 kg
- ColourBlack
- Audio output channels2.0 channels
- Speakers connectivity typeBanana connector/Binding posts
- PurposeHome
Overview
- Connectivity
- Wired
- Weight
- 10.2 kg
- Colour
- Black
- Audio output channels
- 2.0 channels
- Speakers connectivity type
- Banana connector/Binding posts
- Purpose
- Home
- Brand
- Yamaha
- Category
- Audio Amplifier
- Model
- A-S500
- Part numbers
- A-S500B, A-S500S, AS500-BL
- EAN / UPC
- 4957812481922, 4957812481991, 4957812481908
- Also known as
- Yamaha A-S500 2.0 channels Home Black
Specifications
28 specifications in 8 groups
Audio
| Specification | Value |
|---|---|
| Audio output channels | 2.0 channels |
| Peak power per channel | 120 W |
| Amplifier class | A/B |
| Total Harmonic Distortion (THD) | 0.015% |
| Signal-to-Noise Ratio (SNR) | 100 dB |
| RMS power output per channel (4 Ohm) | 120 W |
| RMS power output per channel (8 Ohm) | 85 W |
| Dynamic power per channel (4 Ohm) | 185 W |
| Dynamic power per channel (8 Ohm) | 130 W |
| Frequency range | 10 - 100000 Hz |
Ports & interfaces
| Specification | Value |
|---|---|
| Speakers connectivity type | Banana connector/Binding posts |
| Audio (L/R) in | 6 |
| Audio (L/R) out | 2 |
| Headphone outputs | 1 |
Technical details
| Specification | Value |
|---|---|
| Purpose | Home |
| Connectivity technology | Wired |
| Product colour | Black |
| Volume control | Rotary |
Display
| Specification | Value |
|---|---|
| Built-in display | No |
Power
| Specification | Value |
|---|---|
| Power consumption (standby) | 0.5 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 434.8 mm |
| Depth | 387.3 mm |
| Height | 152.4 mm |
| Weight | 10.2 kg |
Indication
| Specification | Value |
|---|---|
| LED indicators | Yes |
Packaging content
| Specification | Value |
|---|---|
| User guide | Yes |
| Manual | Yes |
| Remote control included | Yes |
