Commercial Audio PM4100 2.0 channels Performance/stage Black
Model PM4100Part no. 920-01888-00002EAN 810039105214
51 specifications
- ConnectivityWired
- Weight500 g
- ColourBlack
- Audio output channels2.0 channels
- Speakers connectivity typeRCA/Euroblock
- PurposePerformance/stage
Overview
- Connectivity
- Wired
- Weight
- 500 g
- Colour
- Black
- Audio output channels
- 2.0 channels
- Speakers connectivity type
- RCA/Euroblock
- Purpose
- Performance/stage
- Brand
- Biamp
- Category
- Audio Amplifier
- Model
- PM4100
- Part number
- 920-01888-00002
- EAN / UPC
- 810039105214
- Also known as
- Biamp Commercial Audio PM4100 2.0 channels Performance/stage Black
Specifications
51 specifications in 9 groups
Audio
| Specification | Value |
|---|---|
| Audio output channels | 2.0 channels |
| Amplifier class | D |
| RMS power output per channel (4 Ohm) | 35 W |
| RMS power output per channel (8 Ohm) | 25 W |
| Gain | 12 dB |
| Bridge-mode power output per channel (4 Ohm) | 56 W |
| Bridge-mode power output per channel (8 Ohm) | 34 W |
| Input impedance | 100000 Ω |
| Output impedance | 100 Ω |
| Audio quality | 16 bit |
Ports & interfaces
| Specification | Value |
|---|---|
| Speakers connectivity type | RCA/Euroblock |
| USB 2.0 ports quantity | 1 |
| USB port type | USB Type-B |
| USB version | 2.0 |
| DC-in jack | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Ethernet LAN data rates | 10,100 Mbit/s |
| GPIO connector type | 5-pin Euroblock |
| GPIO ports quantity | 1 |
| Line inputs (RCA) | 8 |
| Number of Euroblock output connectors | 1 |
| RS-232 connector type | 3-pin Euroblock |
| RS-232 ports | 2 |
Technical details
| Specification | Value |
|---|---|
| Purpose | Performance/stage |
| Connectivity technology | Wired |
| Product colour | Black |
| Bass adjustment | Yes |
| Treble adjustment | Yes |
| Bridge function | Yes |
| Compliance certificates | CE, Federal Communications Commission (FCC), RoHS |
| Equalizer | Yes |
| Sustainability compliance | Yes |
| Warranty period | 5 year(s) |
Power
| Specification | Value |
|---|---|
| Power source type | DC, PoE |
| DC input voltage | 12 V |
| Power consumption (typical) | 5 W |
| Power consumption (Power over Ethernet (PoE)) | 7 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 218 mm |
| Depth | 70 mm |
| Height | 37 mm |
| Weight | 500 g |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 30 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Operating altitude | 0 - 2000 m |
Indication
| Specification | Value |
|---|---|
| LED indicators | Yes |
Packaging data
| Specification | Value |
|---|---|
| Package width | 285 mm |
| Package depth | 190 mm |
| Package height | 55.1 mm |
| Package weight | 860 g |
Logistics data
| Specification | Value |
|---|---|
| Export Control Classification Number (ECCN) | EAR99 |
| Harmonized System (HS) code | 8518402000 |
