Commercial Audio CHAMP-4 4.0 channels Performance/stage Black
Model CHAMP-4Part no. 920-01537-00002EAN 5420035212356
37 specifications
- ConnectivityWired
- Weight7.5 kg
- ColourBlack
- Audio output channels4.0 channels
- Speakers connectivity typeRCA/Binding post
- PurposePerformance/stage
Overview
- Connectivity
- Wired
- Weight
- 7.5 kg
- Colour
- Black
- Audio output channels
- 4.0 channels
- Speakers connectivity type
- RCA/Binding post
- Purpose
- Performance/stage
- Brand
- Biamp
- Category
- Audio Amplifier
- Model
- CHAMP-4
- Part number
- 920-01537-00002
- EAN / UPC
- 5420035212356
- Also known as
- Biamp Commercial Audio CHAMP-4 4.0 channels Performance/stage Black
Specifications
37 specifications in 7 groups
Audio
| Specification | Value |
|---|---|
| Audio output channels | 4.0 channels |
| Total Harmonic Distortion (THD) | 0.1% |
| Signal-to-Noise Ratio (SNR) | 100 dB |
| Damping factor | 100 |
| RMS power output per channel (4 Ohm) | 80 W |
| RMS power output per channel (8 Ohm) | 60 W |
| Dynamic power per channel (4 Ohm) | 125 W |
| Dynamic power per channel (8 Ohm) | 75 W |
| Gain | 26 dB |
| Bridge-mode power output per channel (8 Ohm) | 230 W |
| Input impedance | 10000 Ω |
| Frequency range | 20 - 40000 Hz |
Ports & interfaces
| Specification | Value |
|---|---|
| Speakers connectivity type | RCA/Binding post |
| Binding post ports quantity | 8 |
| AC (power) in | Yes |
Technical details
| Specification | Value |
|---|---|
| Purpose | Performance/stage |
| Connectivity technology | Wired |
| Product colour | Black |
| Volume control | Rotary |
| Bridge function | Yes |
| Compliance certificates | CE |
| Cooling type | Passive |
| On/off switch | Yes |
| Country of origin | China |
| Sustainability compliance | Yes |
Power
| Specification | Value |
|---|---|
| AC input voltage | 230 / 400 V |
| AC input frequency | 50 - 60 Hz |
| Power protection features | DC offset, Over current, Short circuit |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 483 mm |
| Depth | 360 mm |
| Height | 44 mm |
| Weight | 7.5 kg |
Indication
| Specification | Value |
|---|---|
| LED indicators | Yes |
Packaging data
| Specification | Value |
|---|---|
| Package width | 220.4 mm |
| Package depth | 224.3 mm |
| Package height | 43.3 mm |
| Package weight | 9.45 kg |
