Commercial Audio MA120 Performance/stage Black
Model MA120Part no. 920-00659-00002EAN 810039101575
34 specifications
- ConnectivityWired
- Weight5 kg
- ColourBlack
- Amplifier classD
- Speakers connectivity typeEuroblock
- PurposePerformance/stage
Overview
- Connectivity
- Wired
- Weight
- 5 kg
- Colour
- Black
- Amplifier class
- D
- Speakers connectivity type
- Euroblock
- Purpose
- Performance/stage
- Brand
- Biamp
- Category
- Audio Amplifier
- Model
- MA120
- Part numbers
- 920-00659-00002, 913.0659.900
- EAN / UPC
- 810039101575, 5420035205334
- Also known as
- Biamp Commercial Audio MA120 Performance/stage Black
Specifications
34 specifications in 10 groups
Audio
| Specification | Value |
|---|---|
| Amplifier class | D |
| Total Harmonic Distortion (THD) | 0.5% |
| Signal-to-Noise Ratio (SNR) | 90 dB |
| RMS rated power | 120 W |
Ports & interfaces
| Specification | Value |
|---|---|
| Speakers connectivity type | Euroblock |
| AC (power) in | Yes |
| Line inputs (RCA) | 4 |
| Microphone in | Yes |
| Pre out port | Yes |
Technical details
| Specification | Value |
|---|---|
| Purpose | Performance/stage |
| Connectivity technology | Wired |
| Product colour | Black |
| Country of origin | China |
Power
| Specification | Value |
|---|---|
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| DC input voltage | 24 V |
| Power consumption (typical) | 120 W |
| Power consumption (standby) | 0.5 W |
| Maximum current | 0.5 A |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 483 mm |
| Depth | 300 mm |
| Height | 89 mm |
| Weight | 5 kg |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 35 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Operating altitude | 0 - 2000 m |
Indication
| Specification | Value |
|---|---|
| LED indicators | Yes |
Packaging data
| Specification | Value |
|---|---|
| Package width | 411.7 mm |
| Package depth | 516.9 mm |
| Package height | 190 mm |
| Package weight | 7.2 kg |
Packaging content
| Specification | Value |
|---|---|
| Manual | Yes |
Logistics data
| Specification | Value |
|---|---|
| Export Control Classification Number (ECCN) | EAR99 |
| Harmonized System (HS) code | 8518402000 |
