60W Mono Hi-Z Power Amplifier
Model AP106Part no. AP106-AT-GEAN 4710469342080
35 specifications
- ConnectivityWired
- Weight1.23 kg
- ColourBlack
- Peak power per channel120 W
- Speakers connectivity typeEuroblock
- PurposeHome
Overview
- Connectivity
- Wired
- Weight
- 1.23 kg
- Colour
- Black
- Peak power per channel
- 120 W
- Speakers connectivity type
- Euroblock
- Purpose
- Home
- Brand
- ATEN
- Category
- Audio Amplifier
- Model
- AP106
- Part numbers
- AP106-AT-G, AP106-AT-E
- EAN / UPC
- 4710469342080
- Also known as
- ATEN 60W Mono Hi-Z Power Amplifier
Specifications
35 specifications in 9 groups
Audio
| Specification | Value |
|---|---|
| Peak power per channel | 120 W |
| Amplifier class | D |
| Input impedance | 20000 Ω |
| Output impedance | 160 Ω |
| Frequency range | 80 - 20000 Hz |
Ports & interfaces
| Specification | Value |
|---|---|
| Speakers connectivity type | Euroblock |
| AC (power) in | Yes |
| Microphone in | Yes |
Technical details
| Specification | Value |
|---|---|
| Purpose | Home |
| Connectivity technology | Wired |
| Product colour | Black |
| Cables included | AC |
| Compliance certificates | CE, UKCA |
| Master (outer) case volume | 36528.73 cm³ |
| Material | Metal |
| Country of origin | Taiwan |
| Sustainability compliance | Yes |
Power
| Specification | Value |
|---|---|
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Maximum current | 1 A |
| Power protection features | Over voltage, Overheating, Overload, Under voltage |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 157.2 mm |
| Depth | 200 mm |
| Height | 44 mm |
| Weight | 1.23 kg |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
Packaging data
| Specification | Value |
|---|---|
| Package weight | 1.82 kg |
| Package volume | 9910.9 cm³ |
Packaging content
| Specification | Value |
|---|---|
| Manual | Yes |
Logistics data
| Specification | Value |
|---|---|
| Master (outer) case width | 370 mm |
| Master (outer) case length | 427 mm |
| Master (outer) case height | 232 mm |
| Master (outer) case gross weight | 6.12 kg |
