Modena Hub
Model Modena HubPart no. 920-01736-00002EAN 810039101780
36 specifications
- ConnectivityHDMI
- TypeDesktop
- Weight1.1 kg
- ColourBlack, White
- Maximum resolution (HDMI)1920 x 1080 pixels
- Reset buttonYes
Overview
- Connectivity
- HDMI
- Type
- Desktop
- Weight
- 1.1 kg
- Colour
- Black, White
- Maximum resolution (HDMI)
- 1920 x 1080 pixels
- Reset button
- Yes
- Brand
- Biamp
- Category
- Wireless Presentation System
- Model
- Modena Hub
- Part number
- 920-01736-00002
- EAN / UPC
- 810039101780
- Also known as
- Biamp Modena Hub wireless presentation system HDMI Desktop
Specifications
36 specifications in 10 groups
Design
| Specification | Value |
|---|---|
| Form factor | Desktop |
| Product colour | Black, White |
Features
| Specification | Value |
|---|---|
| Maximum resolution (HDMI) | 1920 x 1080 pixels |
| Supported graphics resolutions | 1280 x 720 (HD 720), 1920 x 1080 (HD 1080) |
| Supported video modes | 720p, 1080p |
| Maximum frame rate | 30 fps |
Management features
| Specification | Value |
|---|---|
| Reset button | Yes |
| On/off switch | Yes |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 1000 Mbit/s |
| Cabling technology | 10/100/1000Base-T(X) |
Ports & interfaces
| Specification | Value |
|---|---|
| Interface | HDMI |
| HDMI input ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| DC-in jack | Yes |
Power
| Specification | Value |
|---|---|
| Power source type | DC |
| Input voltage | 12 V |
System requirements
| Specification | Value |
|---|---|
| Windows operating systems supported | Windows 10 |
| Mac compatibility | Yes |
| Mac operating systems supported | Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 11.0 Big Sur |
| Mobile operating systems supported | Android 10.0, Android 11.0, Android 12.0, Android 8.0, Android 9.0, iOS 11.0, iOS 11.4, iOS 12, iOS 13, iOS 14.5, iOS 15 |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage temperature (T-T) | -20 - 60 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 160 mm |
| Depth | 132 mm |
| Height | 51 mm |
| Weight | 1.1 kg |
| Package width | 260.4 mm |
| Package depth | 209.6 mm |
| Package height | 95.3 mm |
| Package weight | 1.81 kg |
Logistics data
| Specification | Value |
|---|---|
| Country of origin | Italy |
| Export Control Classification Number (ECCN) | 5A992 |
| Harmonized System (HS) code | 8517620050 |
