ClickShare C‑10
Model ClickShare C‑10Part no. R9861611CNB1EAN 5415334038783
48 specifications
- SpeedWi-Fi 5 (802.11ac)
- ConnectivityHDMI
- TypeDesktop
- Weight900 g
- ColourBlack
- Supported graphics resolutions3840 x 2160
Overview
- Speed
- Wi-Fi 5 (802.11ac)
- Connectivity
- HDMI
- Type
- Desktop
- Weight
- 900 g
- Colour
- Black
- Supported graphics resolutions
- 3840 x 2160
- Brand
- Barco
- Category
- Wireless Presentation System
- Model
- ClickShare C‑10
- Part numbers
- R9861611CNB1, R9861611EUB1, R9861611USB1
- EAN / UPC
- 5415334038783, 5415334038813, 8717472608895
- Also known as
- Barco ClickShare C‑10 wireless presentation system HDMI Desktop
Specifications
48 specifications in 11 groups
Design
| Specification | Value |
|---|---|
| Form factor | Desktop |
| Product colour | Black |
| LED indicators | Yes |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
Features
| Specification | Value |
|---|---|
| Supported graphics resolutions | 3840 x 2160 |
| Supported video modes | 2160p |
| AirPlay mirroring | Yes |
| Maximum frame rate | 30 fps |
| Google Cast | Yes |
| Miracast | Yes |
| Number of users | 32 user(s) |
| Smartphone/tablet remote support | Yes |
Management features
| Specification | Value |
|---|---|
| Web-based management | Yes |
| On/off switch | Yes |
Network
| Specification | Value |
|---|---|
| Wi-Fi standards | 802.11a, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| Frequency band | 2.4, 5 GHz |
| Dual-band | Yes |
| Ethernet LAN | Yes |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11g, IEEE 802.11n, IEEE 802.15.1 |
| Security algorithms | 802.1x RADIUS, WPA2-PSK |
| Maximum operating distance | 30 m |
Ports & interfaces
| Specification | Value |
|---|---|
| Interface | HDMI |
| Number of HDMI outputs | 1 |
| HDMI version | 1.4b |
| Ethernet LAN (RJ-45) ports | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| DC-in jack | Yes |
Power
| Specification | Value |
|---|---|
| Power source type | DC |
| Input voltage | 110 - 220 V |
| Power consumption (max) | 24 W |
| Suitable for use in country/location | China |
System requirements
| Specification | Value |
|---|---|
| Windows operating systems supported | Windows 11 Enterprise x64, Windows 10, Windows 11 Home, Windows 10 Education, Windows 11 Pro, Windows 10 Education x64, Windows 11 x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 P |
| Mac compatibility | Yes |
| Mac operating systems supported | Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura, Mac OS X 14.0 Sonoma, Mac OS X 15.0 Sequoia |
| Mobile operating systems supported | Android 10.0, Android 11.0, Android 12.0, Android 13.0, Android 14.0, Android 9.0, iOS 12, iOS 13, iOS 13.4, iOS 14, iOS 14.5, iOS 15, iOS 16 |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 0 - 85% |
| Storage temperature (T-T) | -20 - 60 °C |
| Storage relative humidity (H-H) | 0 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 135 mm |
| Depth | 135 mm |
| Height | 34 mm |
| Weight | 900 g |
Packaging content
| Specification | Value |
|---|---|
| Remote control included | Yes |
Technical details
| Specification | Value |
|---|---|
| Warranty period | 1 year(s) |
