870H-53A v2
Model 870H-53A v2Part no. 91-025-019001BEAN 4718937522286
40 specifications
- Weight328 g
- ColourWhite
- Ethernet WANYes
- Ethernet interface typeFast Ethernet
- Dual-bandNo
- Ethernet LAN (RJ-45) ports4
Overview
- Weight
- 328 g
- Colour
- White
- Ethernet WAN
- Yes
- Ethernet interface type
- Fast Ethernet
- Dual-band
- No
- Ethernet LAN (RJ-45) ports
- 4
- Brand
- Zyxel
- Category
- Wired Router
- Model
- 870H-53A v2
- Part numbers
- 91-025-019001B, 3824
- EAN / UPC
- 4718937522286, 4718937530359
- Also known as
- Zyxel Prestige 870H-53A v2 wired router Fast Ethernet White
Specifications
40 specifications in 14 groups
WAN connection
| Specification | Value |
|---|---|
| Ethernet WAN | Yes |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.1ag, IEEE 802.3, IEEE 802.3u, IEEE 802.3x |
| Ethernet interface type | Fast Ethernet |
| Ethernet LAN | Yes |
| Cabling technology | 10/100Base-T(X) |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Full duplex | Yes |
Wireless LAN features
| Specification | Value |
|---|---|
| Dual-band | No |
DSL features
| Specification | Value |
|---|---|
| VDSL2 | Yes |
| Upstream data rate | 45 Mbit/s |
| Downstream data rate | 100 Mbit/s |
Management features
| Specification | Value |
|---|---|
| Web-based management | Yes |
| Quality of Service (QoS) support | Yes |
| Firmware upgradeable | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 4 |
| DC-in jack | Yes |
Protocols
| Specification | Value |
|---|---|
| DHCP server | No |
| Management protocols | Telnet, FTP |
Security
| Specification | Value |
|---|---|
| Security algorithms | SSH |
| Firewall | Yes |
| Authentication method | PAP, CHAP |
| MAC address filtering | Yes |
Features
| Specification | Value |
|---|---|
| Safety | CSA 60950-1, UL 60950-1, EN 60950-1: 2001+A11, IEC 60950-1: 2001 |
| Electromagnetic compatibility | EN55022 Class B, EN61000-3-2: 2000, EN61000-3-3: 1995+A1: 2001, FCC Part 15 (Class B) |
Design
| Specification | Value |
|---|---|
| Product colour | White |
| Rack mounting | No |
| LED indicators | Yes |
Power
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | No |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 20 - 85% |
| Storage relative humidity (H-H) | 20 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 189 mm |
| Depth | 132 mm |
| Height | 40 mm |
| Weight | 328 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 238 mm |
| Package depth | 203 mm |
| Package height | 60.5 mm |
| Package weight | 711 g |
