Omada Pro VPN Router with
10G Ports
Model G611EAN 840030711480
61 specifications
- ProcessorARM Cortex-A72
- Memory4096 MB
- ColourGrey
- Ethernet WANYes
- Networking standardsIEEE 802.1Q
- Ethernet LAN (RJ-45) ports8
Overview
- Processor
- ARM Cortex-A72
- Memory
- 4096 MB
- Colour
- Grey
- Ethernet WAN
- Yes
- Networking standards
- IEEE 802.1Q
- Ethernet LAN (RJ-45) ports
- 8
- Brand
- TP-Link
- Category
- Wired Router
- Model
- G611
- Part number
- G611
- EAN / UPC
- 840030711480, 4895252505870
- Also known as
- TP-Link Omada Pro VPN Router with 10G Ports
Specifications
61 specifications in 12 groups
WAN connection
| Specification | Value |
|---|---|
| Ethernet WAN | Yes |
| DSL WAN | No |
| SIM card slot | No |
| 3G/4G USB modem compatibility | No |
| SFP WAN | Yes |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.1Q |
| Ethernet interface type | Gigabit Ethernet |
| Cabling technology | 10/100/1000Base-T(X) |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Static route | Yes |
| VLAN support | Yes |
| Traffic control | Yes |
| Port forwarding | Yes |
| Policy-based routing | Yes |
| Concurrent connections | 2300000 |
Management features
| Specification | Value |
|---|---|
| Quality of Service (QoS) support | Yes |
| Universal Plug and Play (UPnP) | Yes |
| Reset button | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 8 |
| WAN/Ethernet LAN ports quantity | 8 |
| SFP module slots quantity | 1 |
| SFP+ module slots quantity | 2 |
| USB ports quantity | 2 |
| USB version | 3.2 Gen 1 (3.1 Gen 1) |
| DC-in jack | Yes |
Protocols
| Specification | Value |
|---|---|
| DHCP client | Yes |
| DHCP server | Yes |
| Routing protocols | RIP, OSPF |
Security
| Specification | Value |
|---|---|
| Security algorithms | 3DES, 128-bit AES, 192-bit AES, 256-bit AES, DES, SHA-1, SHA-256, SHA-384, SHA-512 |
| URL filtering | Yes |
| IP address filtering | Yes |
| ARP attack prevention | Yes |
| ICMP attack prevention | Yes |
| Access Control List (ACL) | Yes |
| Network address translation (NAT) | Yes |
| Guest access | Yes |
| System event log | Yes |
| VPN tunnels quantity | 500 |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Quick start guide | Yes |
Features
| Specification | Value |
|---|---|
| Built-in processor | Yes |
| Processor manufacturer | ARM |
| Processor model | ARM Cortex-A72 |
| Processor frequency | 2.2 MHz |
| Flash memory | 256 MB |
| Internal memory | 4096 MB |
| Internal memory type | DDR4 |
| Certification | CE, FCC, RoHS |
Design
| Specification | Value |
|---|---|
| Product colour | Grey |
| LED indicators | Yes |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 19.12 W |
| Power consumption (max) | 26.36 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 440 mm |
| Depth | 220 mm |
| Height | 44 mm |
