TL-R470T+ V6
Model TL-R470T+ V6
28 specifications
- ColourBlack
- Ethernet WANYes
- Ethernet LAN (RJ-45) ports5
- Flash memory16 MB
- Antenna typeNot supported
- Power source typeDC
Overview
- Colour
- Black
- Ethernet WAN
- Yes
- Ethernet LAN (RJ-45) ports
- 5
- Flash memory
- 16 MB
- Antenna type
- Not supported
- Power source type
- DC
- Brand
- TP-Link
- Category
- Wired Router
- Model
- TL-R470T+ V6
- Part number
- TL-R470T+ V6
- Also known as
- TP-Link TL-R470T+ V6 wired router Black
Specifications
28 specifications in 13 groups
WAN connection
| Specification | Value |
|---|---|
| Ethernet WAN | Yes |
| DSL WAN | No |
| SIM card slot | No |
| 3G/4G USB modem compatibility | No |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3x |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Concurrent connections | 10000 |
Management features
| Specification | Value |
|---|---|
| Web-based management | Yes |
| Reset button | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 5 |
Protocols
| Specification | Value |
|---|---|
| DHCP client | Yes |
| DHCP server | Yes |
Security
| Specification | Value |
|---|---|
| Firewall | Yes |
Features
| Specification | Value |
|---|---|
| Flash memory | 16 MB |
| Certification | CE, FCC, RoHS |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| LED indicators | LAN, Power, System, WAN, WLAN |
Antenna
| Specification | Value |
|---|---|
| Antenna type | Not supported |
Power
| Specification | Value |
|---|---|
| Power source type | DC |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 158 mm |
| Depth | 101 mm |
| Height | 25 mm |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85176990 |
