TL-ER5120 V4
Model TL-ER5120 V4
43 specifications
- Memory256 MB
- ColourBlack
- Ethernet WANYes
- Ethernet interface typeFast Ethernet, Gigabit Ethernet
- Ethernet LAN (RJ-45) ports5
- Flash memory32 MB
Overview
- Memory
- 256 MB
- Colour
- Black
- Ethernet WAN
- Yes
- Ethernet interface type
- Fast Ethernet, Gigabit Ethernet
- Ethernet LAN (RJ-45) ports
- 5
- Flash memory
- 32 MB
- Brand
- TP-Link
- Category
- Wired Router
- Model
- TL-ER5120 V4
- Part number
- TL-ER5120 V4
- Also known as
- TP-Link TL-ER5120 V4 wired router Fast Ethernet, Gigabit Ethernet Black
Specifications
43 specifications in 12 groups
WAN connection
| Specification | Value |
|---|---|
| Ethernet WAN | Yes |
| DSL WAN | No |
| SIM card slot | No |
| 3G/4G USB modem compatibility | No |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u |
| Ethernet interface type | Fast Ethernet, Gigabit Ethernet |
| Cabling technology | 10/100/1000Base-T(X) |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Throughput | 0.8 Gbit/s |
| VLAN support | Yes |
| Policy-based routing | Yes |
| Concurrent connections | 150000 |
Management features
| Specification | Value |
|---|---|
| Web-based management | Yes |
| Universal Plug and Play (UPnP) | Yes |
| Reset button | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 5 |
| DC-in jack | Yes |
Protocols
| Specification | Value |
|---|---|
| DHCP client | Yes |
| DHCP server | Yes |
| Supported protocols | TCP/IP, DHCP, ICMP, NAT, PPPoE, SNTP, HTTP, DNS, PPTP, L2TP |
Security
| Specification | Value |
|---|---|
| MAC address filtering | Yes |
| ICMP attack prevention | Yes |
| Network address translation (NAT) | Yes |
| NAT functionality | One-to-One NAT, Multi-nets NAT, Virtual Server, Port Triggering FTP/H.323/SIP/IPsec/PPTP ALG, UPnP |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
Features
| Specification | Value |
|---|---|
| Flash memory | 32 MB |
| Internal memory | 256 MB |
| Certification | CE, FCC |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Rack mounting | Yes |
| Rack capacity | 1U |
| LED indicators | Activity, Link, Power, Speed, System, WAN |
| On/off switch | Yes |
Power
| Specification | Value |
|---|---|
| Power source type | AC |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 440 mm |
| Depth | 220 mm |
| Height | 44 mm |
