TD-8811 wired router Black, White
Model TD-8811EAN 845973030261
39 specifications
- Speed0.1 Gbit/s
- ConnectivityWired
- Weight300 g
- ColourBlack, White
- Networking standardsIEEE 802.1d
- ADSLYes
Overview
- Speed
- 0.1 Gbit/s
- Connectivity
- Wired
- Weight
- 300 g
- Colour
- Black, White
- Networking standards
- IEEE 802.1d
- ADSL
- Yes
- Brand
- TP-Link
- Category
- Wired Router
- Model
- TD-8811
- Part number
- TD-8811
- EAN / UPC
- 845973030261
- Also known as
- TP-Link TD-8811 wired router Black, White
Specifications
39 specifications in 11 groups
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.1d |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Data transfer rate | 24 Mbit/s |
| Full duplex | Yes |
| ATM features | UNI 3.1, 5-AAL5, UBR, CBR, VBR-rt, VBR-nrt, RFC 1483 |
DSL features
| Specification | Value |
|---|---|
| ADSL | Yes |
| Upstream data rate | 3.5 Mbit/s |
| Downstream data rate | 24 Mbit/s |
| DSL specification | ANSI T1.413 Issue 2, ITU-T G.992.1, ITU-T G.992.2, ITU-T G.994.1, ITU-T G.992.3, ITU-T G.992.5 |
Management features
| Specification | Value |
|---|---|
| Web-based management | Yes |
| Quality of Service (QoS) support | Yes |
| Firmware upgradeable | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
| RJ-11 ports quantity | 1 |
| USB ports quantity | 1 |
| DC-in jack | Yes |
Protocols
| Specification | Value |
|---|---|
| DHCP client | Yes |
| DHCP server | Yes |
| DMZ support | Yes |
| Routing protocols | IP |
| Supported network protocols | PPPoE, RFC 2364 |
Security
| Specification | Value |
|---|---|
| Security algorithms | 802.1x RADIUS |
| Firewall security | Network address translation (NAT) firewall, Stateful packet inspection (SPI) firewall |
| MAC address filtering | Yes |
| IP address filtering | Yes |
| Filtering description | Domain |
Design
| Specification | Value |
|---|---|
| Product colour | Black, White |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 4.1 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 300 g |
Other features
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| Dimensions (WxDxH) | 165 x 108 x 28 mm |
| Maximum data transfer rate | 0.1 Gbit/s |
| Supported data transfer rates | 10/100 Mbps |
| Connectivity LEDs | Yes |
