BR200 wired router 5 Gigabit Ethernet White
Model BR200Part no. BR200-100PESEAN 606449152913
50 specifications
- Storage1 GB
- Weight1.55 kg
- ColourWhite
- Ethernet WANYes
- Networking standardsIEEE 802.1Q
- Ethernet LAN (RJ-45) ports4
Overview
- Storage
- 1 GB
- Weight
- 1.55 kg
- Colour
- White
- Ethernet WAN
- Yes
- Networking standards
- IEEE 802.1Q
- Ethernet LAN (RJ-45) ports
- 4
- Brand
- NETGEAR
- Category
- Wired Router
- Model
- BR200
- Part numbers
- BR200-100PES, BR200-100UKS
- EAN / UPC
- 606449152913, 10606449152910, 606449152920
- Also known as
- NETGEAR BR200 wired router 5 Gigabit Ethernet White
Specifications
50 specifications in 13 groups
WAN connection
| Specification | Value |
|---|---|
| Ethernet WAN | Yes |
| DSL WAN | No |
| SIM card slot | No |
| 3G/4G USB modem compatibility | No |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.1Q |
| Ethernet interface type | 5 Gigabit Ethernet |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Throughput | 0.924 Gbit/s |
| VLAN support | Yes |
| Port forwarding | Yes |
| Number of users | 256 user(s) |
Management features
| Specification | Value |
|---|---|
| Web-based management | Yes |
| Quality of Service (QoS) support | Yes |
| Universal Plug and Play (UPnP) | Yes |
| Firmware upgradeable | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 4 |
| DC-in jack | Yes |
Protocols
| Specification | Value |
|---|---|
| DHCP client | Yes |
| DHCP server | Yes |
| DMZ support | Yes |
| Routing protocols | RIP-1, RIP-2 |
| VoIP protocols | SIP ALG |
Security
| Specification | Value |
|---|---|
| Security algorithms | AES, DES, SSL/TLS |
| Firewall | Yes |
| Firewall security | Stateful Packet Inspection (SPI), Port/Service Blocking, Denial-of-service (DoS) Prevention, Stealth Mode, Block TCP Flood, Block UDP Flood, WAN/LAN Ping Response Control |
| MAC address filtering | Yes |
| Network address translation (NAT) | Yes |
| VPN support | SSL Message Integrity: MD5, SHA-1, MAC-MD5/SHA-1, HMAC-MD5/SHA-1 SSL Certificate Support: RSA, Diffie-Hellman, Self L2TP Server PPTP Server |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Quick installation guide | Yes |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
Features
| Specification | Value |
|---|---|
| Built-in processor | Yes |
| Processor frequency | 1.7 MHz |
| Internal storage capacity | 1 GB |
| Flash memory | 128 MB |
| Certification | Environment: RoHS Safety: CE/LVD, cUL EMI: FCC Part 15 Class B, CE mark, C-Tick Class B, VCCI |
Design
| Specification | Value |
|---|---|
| Product colour | White |
| LED indicators | Yes |
| On/off switch | Yes |
Power
| Specification | Value |
|---|---|
| Power source type | AC |
| Output voltage | 12 V |
| Output current | 1.5 A |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 45 °C |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating relative humidity (H-H) | 0 - 90% |
| Storage relative humidity (H-H) | 0 - 95% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 314 mm |
| Depth | 187.5 mm |
| Height | 43.6 mm |
| Weight | 1.55 kg |
