LevelOne ADSL2+ Modem Router (1 LAN, 1 WAN, 1 USB Port), Annex A
Model FBR-1161AEAN 4015867132555
42 specifications
- ColourBlack
- Ethernet WANYes
- Dual-bandNo
- Ethernet LAN (RJ-45) ports1
- Power source typeAC
- Operating temperature (T-T)0 - 40 °C
Overview
- Colour
- Black
- Ethernet WAN
- Yes
- Dual-band
- No
- Ethernet LAN (RJ-45) ports
- 1
- Power source type
- AC
- Operating temperature (T-T)
- 0 - 40 °C
- Brand
- LevelOne
- Category
- Wired Router
- Model
- FBR-1161A
- Part number
- FBR-1161A
- EAN / UPC
- 4015867132555
- Also known as
- LevelOne ADSL2+ Modem Router (1 LAN, 1 WAN, 1 USB Port), Annex A
Specifications
42 specifications in 13 groups
WAN connection
| Specification | Value |
|---|---|
| Ethernet WAN | Yes |
| DSL WAN | Yes |
| 3G/4G USB modem compatibility | Yes |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100 Mbit/s |
Wireless LAN features
| Specification | Value |
|---|---|
| Dual-band | No |
| High power | No |
DSL features
| Specification | Value |
|---|---|
| ADSL2+ | Yes |
Management features
| Specification | Value |
|---|---|
| Web-based management | Yes |
| Reset button | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
| RJ-11 ports quantity | 1 |
| USB ports quantity | 1 |
| USB version | 1.1 |
| DC-in jack | Yes |
Protocols
| Specification | Value |
|---|---|
| DHCP client | Yes |
| DHCP server | No |
| DMZ support | Yes |
| Routing protocols | RIP-1, RIP-2 |
| Supported network protocols | DDNS, UPnP, SNTP, DNS, IGMP |
| Supported protocols | AAL5, RFC 2684, RFC 1483, VC, LLC, PPPoE, RFC 2364, OAM F4/F5 |
Security
| Specification | Value |
|---|---|
| Firewall | Yes |
| Firewall security | Network address translation (NAT) firewall |
| MAC address filtering | No |
| URL filtering | Yes |
| IP address filtering | Yes |
| DoS attack prevention | Yes |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Rack mounting | No |
| Country of origin | China |
Power
| Specification | Value |
|---|---|
| Power source type | AC |
| Input current | 1 A |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating relative humidity (H-H) | 20 - 95% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 132 mm |
| Depth | 94 mm |
| Height | 35 mm |
Packaging data
| Specification | Value |
|---|---|
| Package width | 163 mm |
| Package depth | 229 mm |
| Package height | 100 mm |
| Package weight | 780 g |
