FRITZ!Box Fon 5124 Annex B
Model FRITZ!Box Fon 5124 Annex BPart no. 20002381EAN 4023125023811
31 specifications
- Speed0.100 Gbit/s
- ConnectivityWired
- Weight852 g
- Supports ISDN connectionYes
- Ethernet LAN (RJ-45) ports4
- Power over Ethernet (PoE)No
Overview
- Speed
- 0.100 Gbit/s
- Connectivity
- Wired
- Weight
- 852 g
- Supports ISDN connection
- Yes
- Ethernet LAN (RJ-45) ports
- 4
- Power over Ethernet (PoE)
- No
- Brand
- FRITZ!
- Category
- Wired Router
- Model
- FRITZ!Box Fon 5124 Annex B
- Part number
- 20002381
- EAN / UPC
- 4023125023811
- Also known as
- FRITZ! Box Fon 5124 Annex B wired router
Specifications
31 specifications in 9 groups
Network
| Specification | Value |
|---|---|
| Supports ISDN connection | Yes |
DSL features
| Specification | Value |
|---|---|
| ADSL | Yes |
| Upstream data rate | 1 Mbit/s |
| Downstream data rate | 24 Mbit/s |
| DSL specification | ADSL, ADSL 2+ |
Management features
| Specification | Value |
|---|---|
| Web-based management | Yes |
| Quality of Service (QoS) support | Yes |
| Universal Plug and Play (UPnP) | Yes |
| Reset button | No |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 4 |
| RJ-11 ports quantity | 1 |
| USB ports quantity | 1 |
| DC-in jack | Yes |
Protocols
| Specification | Value |
|---|---|
| DHCP client | Yes |
| DHCP server | Yes |
| Switching protocols | Ethernet |
| Data link protocols | Ethernet, Fast Ethernet |
| Management protocols | TR069 TR064 |
| VoIP protocols | SIP, SDP, RTP |
| Supported protocols | ITU G.992.1 |
Security
| Specification | Value |
|---|---|
| Firewall security | Network address translation (NAT) firewall |
| System event log | Yes |
Power
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | No |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 852 g |
Other features
| Specification | Value |
|---|---|
| Compatible operating systems | Windows XP, 2000, Me, 98; Linux (SuSE 9.0); Mac OS X 10.3.3 + |
| Connectivity technology | Wired |
| Dimensions (WxDxH) | 240 x 305 x 70 mm |
| Management platform | TR069 |
| Maximum data transfer rate | 0.100 Gbit/s |
| Supported WAN type | ADSL or Ethernet |
| Connectivity LEDs | DSL / Fixed line / VoIP |
