HDMI Audio Extractor with 4K
60Hz Support
Model HD202AEAN 065030878609
36 specifications
- Weight320 g
- ColourBlack
- Maximum video resolution4096 x 2160 pixels
- Audio output channels5.1 channels
- Host interfaceHDMI
- External power adapterYes
Overview
- Weight
- 320 g
- Colour
- Black
- Maximum video resolution
- 4096 x 2160 pixels
- Audio output channels
- 5.1 channels
- Host interface
- HDMI
- External power adapter
- Yes
- Brand
- StarTech.com
- Category
- Video Signal Converter
- Model
- HD202A
- Part number
- HD202A
- EAN / UPC
- 065030878609
- Also known as
- StarTech.com HDMI Audio Extractor with 4K 60Hz Support
Specifications
36 specifications in 9 groups
Features
| Specification | Value |
|---|---|
| Product colour | Black |
Video
| Specification | Value |
|---|---|
| Maximum video resolution | 4096 x 2160 pixels |
| Video resolutions | 1280 x 720,1920 x 1080,1920 x 1200,3840 x 2160,4096 x 2160 |
| Maximum refresh rate | 60 Hz |
Audio
| Specification | Value |
|---|---|
| Audio output channels | 5.1 channels |
Ports & interfaces
| Specification | Value |
|---|---|
| Host interface | HDMI |
| Audio output | RCA + Toslink |
| Video in | HDMI |
| Video out | HDMI |
Power
| Specification | Value |
|---|---|
| External power adapter | Yes |
| Input current | 0.4 A |
| Input voltage | 100 - 240 V |
| Operating current | 1 A |
| Operating voltage | 5 V |
| Power plug type | Type M |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 45 °C |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 80 mm |
| Depth | 90 mm |
| Height | 22 mm |
| Weight | 320 g |
Packaging data
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Screws included | Yes |
| Number of screws | 2 |
| Included power plug types | ANZ, EU, NA, UK |
| Mounting bracket(s) included | Yes |
| Package width | 157 mm |
| Package depth | 195 mm |
| Package height | 52 mm |
| Package weight | 470 g |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85176990 |
| Master (outer) case width | 360 mm |
| Master (outer) case length | 608 mm |
| Master (outer) case height | 308 mm |
| Products per master (outer) case | 30 pc(s) |
